MSI X48 Platinum Series

1-3
Getting Started
Silicon Image Hardware RAID
- Supports RAID 0/ RAID 1/ JBOD mode (for SATA7 & SATA8 only)
- Default mode is RAID 1
1394 (optional)
- Supports 1394 by VIA VT6308P
FDD
- 1 floppy port
- Supports 1 FDD with 360KB, 720KB, 1.2MB, 1.44MB and 2.88MB
Connectors
Back panel
- 1 PS/2 mouse port
- 1 PS/2 keyboard port
- 2 eSATA ports (support Command Based Port Multipliers)
- 8 USB 2.0 Ports
- 2 LAN jacks (10/100/1000)
- 6 flexible audio jacks
- 1 1394 port (optional)
- 1 Optical SPDIF-Out
On-Board Pinheaders / Connectors
- 2 USB 2.0 pinheaders
- 1 1394 pinheader (optional)
- 1 chassis intrusion connector
- 1 SPDIF-out pinheader
- 1 CD-in connector
- 1 front audio pinheader
- 1 serial port connector (optional)
- 1 TPM Module connector (optional)
TPM (optional)
- Supports TPM
Slots
- 2 mazarine PCI Express x16 slots, support PCI Express 2.0 x16
speed
- 2 PCI Express x1 slots
- 2 yellow PCI Express x16 slots, support PCI Express x4 speed
- 1 PCI slot, support 3.3V/ 5V PCI bus Interface
Form Factor
- ATX (30.5cm X 24.5cm)
Mounting
- 9 mounting holes
