MSI X48 Platinum Series User Manual

3-12
MS-7353 Mainboard
USB Controller
This setting allows you to enable/disable the onboard USB controller.
USB Device Legacy Support
Select [Enabled] if you need to use a USB-interfaced device in the operating system.
Onboard LAN Controller
This item is used to enable/disable the onboard 1st LAN controller (Realtek 8111B, the
one next to the USB connector).
LAN Option ROM
This item is used to decide whether to invoke the Boot ROM of the LAN controller.
Onboard 2nd LAN Controller
This item is used to enable/disable the onboard 2nd LAN controller (Intel 82566DC, the
one next to the audio jack).
2nd LAN Option ROM
This item is used to decide whether to invoke the Boot ROM of the 2nd LAN controller.
Onboard IEEE1394 Controller
This item allows you to enable/disable the onboard IEEE1394 controller.
Integrated Peripherals
