Specifications
Continued from previous page
Storage
Intel
®
Z170 Chipset
y 6x SATA 6Gb/s ports*
Support RAID 0, RAID 1, RAID 5 and RAID 10
y 2x M.2 slots (Key M)*
Supports up to PCIe 3.0 x4 and SATA 6Gb/s
Supports 2242/ 2260/ 2280/ 22110 storage devices**
Supports RAID 0 and RAID 1 for M.2 PCIe Storage
devices***
y 1x U.2 port*
Supports PCIe 3.0 x4 NVMe storage
y Supports Intel
®
Smart Response Technology****
* M2_1 and SATA5~6 share the same bandwidth. M2_2 , SATA1~2 and U.2 port
share the same bandwidth. Please refer to page 36 for M.2/ U.2 & SATA
combination table.
** Only M2_1 slot supports type 22110 storage device.
*** M.2 PCIe RAID volume can be created with UEFI BIOS.
****This function will be supported depend on the CPU.
Audio
y Realtek
®
ALC1150 Codec
y 7.1-Channel High Definition Audio
y Supports S/PDIF output
LAN
1x Intel I219 Gigabit LAN controller
Back Panel
Connectors
y 1x PS/2 keyboard/ mouse combo port
y 4x USB 2.0 ports
y 1x DVI-D port
y 1x USB 3.1 Gen2 port
y 1x USB 3.1 Gen2 Type-C port
y 1x HDMI port
y 1x LAN (RJ45) port
y 2x USB 3.1 Gen1 ports
y 1x Optical S/PDIF OUT connector
y 5x OFC audio jacks
