MSI Z77 MPower series User Manual

1-4
Gettng Started
Manboard Spec󰘰catons
Processor Support
3rd Generaton Intel
®
Core™ 7 / Core™ 5 / Core™ 3 / Pentum
®
/ Celeron
®
processors
for LGA 1155 socket
Chpset
Intel
®
Z77 chpset
Memory Support
4x DDR3 DIMMs support for DDR3-1066/1333/1600/1866*/2000*/2133*(OC), 2200*/
2400*/2600*/2667*/2800*/3000*(OC, 22nm CPU requred) MHz up to 32GB max
Supports Dual-Channel mode
Network
Supports LAN 10/100/1000 Fast Ethernet by Realtek
®
8111E
Supports W-F 802.11 b/g/n
Bluetooth
Supports Bluetooth 3.0+HS
Audo
Integrated HD audo codec by Realtek
®
ALC898
8-channel audo wth jack sensng
Complant wth Azala 1.0 Spec
SATA
2x SATA 6Gb/s ports, (SATA1~2) by Intel
®
Z77
4x SATA 3Gb/s ports, (SATA3~6) by Intel
®
Z77
RAID
SATA1~6 support Intel
®
Rapd Storage Technology enterprse (AHCI/ RAID 0/ 1/ 5/
10) by Intel
®
Z77
USB 3.0
6x USB 3.0 rear IO ports, (2 ports by Intel
®
Z77, 4 ports by Renesas
®
uDP72020)
1x USB 3.0 onboard connector by Intel
®
Z77
Mult-GPU
Supports ATI
®
CrossFre
TM
Technology
Supports NVIDIA
®
SLI
TM
Technology
Supports Lucd
®
Vrtu Unversal MVP
Connectors & Buttons
Back panel
1x PS/2 keyboard/ mouse port
1x Clear CMOS button
2x USB 2.0 ports
6x USB 3.0 ports
1x LAN port
1x Optcal S/PDIF-out port
6x audo ports
1x HDMI
®
port*, supportng a maxmum resoluton of 1920x1200
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
■
-
-
-
-
-
-
-
-

MSI Z77 MPower series Specifications

General

Brand	MSI
Model	Z77 MPower series
Category	Motherboard
Language	English
