QM7500 Technical Manual
QM31930/03093 Rev AD Parts List 23
Description Part Number
Quantity per
Package
QM7500 Printhead Assembly
1. Housing, Printhead Top QMRP15875 1
2. Housing, Printhead Bottom QMRP21849 1
3. Clip, Valve Retaining QMRP16053 1
4. Regulator Assembly QMRP15884 1
5. Nozzle Block, 10 mm
Nozzle Block, 7 mm (Optional)
Nozzle Block, 15 mm (Optional)
Nozzle Block, 20 mm (Optional)
QMRP15895
QM22836
QM18154
QM18217
1
1
1
1
6. Tubing, Valve 713, 14H, 16H QMRPJ5010030
004
1
7. Valve, 600LT 12V 600Hz Square Pin QMRP27339 1
8. Board, Square Pin Valve QMRP21501 1
9. Board, Photocell QMRP15876 1
10. Cable, Valve/Photocell Board QMRP17020 1
