7.9 Digital input alarms
ALd
Temperature
alarm delay
Time interval between detection of a temperature alarm and
relative signalling
0 255 min 0
dAO
Temperature
alarm inhibit at
start-up
At start-up of the unit the temperature alarm is inhibited for the
time set in this parameter 0 23,5 h
10
min
0
tbA
Alarm relay
deactivation
n= relay active for the entire duration of the alarm
y= the relay is deactivated by pressing with an alarm in
progress
n
AoP
Polarity according
to relay
(oA3=ALr)
Selects alarm relay open or closed during an alarm. cl=
terminals 1-2 closed during an alarm; op= terminals 1-2 open
during an alarm
oP
Parameter Description Min. Max. U.M.
Factory
settings
i1P
Digital input
polarity
Serves to set alarm signalling on the basis of:
• oP= input is activated by contact opening
• CL= digital input is activated by contact
closing
oP
i1F
Digital input
configuration
Serves to set alarm signalling on the basis of:
• EAL= external alarm (EA on display)
• bAL= critical alarm
• PAL= pressure switch alarm
• dor= door microswitch
• dEF= defrost activation
• AUS= not enabled
• Htr= reverse action (hot-cold)
• FAN= not enabled
• ES= not enabled
• OFb= not enabled
bAL
did
Digital input
alarm delay
Serves to set the time lag before activation of the digital input
alarm
• i1F=EAL or bAL delay between detection and
signalling of an external alarm
• i1F=dor delay on door open alarm signal
• i1F=PAL time for pressure switch operation: if
nPS activations in time did are reached
restarting is manual only by powering off the
unit and then powering it on again
0 255 min. 0
nPS
Number of
pressure switch
activations
At each activation of the digital input the control is blocked; if
nPS activations are reached in time did restarting is manual
only by powering off the unit and then powering it on again.
115 15
odc
Door open control Determines compressor and fan status with door open
• no= fans and compressor operate normally
•Fan= fans OFF
• CPr= compressor OFF
• F-C= compressor and fans OFF
F-C
Parameter Description Min. Max. U.M.
Factory
settings
Table 5 P
ARAMETERS RELATIVE TO ALARMS MANAGEMENT
