MAINTENANCE AND OPERATING MANUAL
Chapter 3 - Technical data
The data inside this manual are not binding and they can be modified by the manufacturer without notice. All rights reserved.
TAEevo015÷351
C HAPTER 3
T ECHNICAL DATA
The main technical data are given on the machine data plate:
ATTENTION
The performance of the unit mainly depends on the flow and temperature of the water in the user circuit and on the temperature of the
thermal exchanger fluid of the condenser. These data are defined during the offer stage.
3.1 Other data relative to the standard machines
3.1.1 Dimensions
See enclosures.
MODEL and CODE
They identify the size of the unit and the type of construction.
MANUAL
This is the code number of the manual.
SERIAL NUMBER
This is the construction number of the unit.
MANUFACTURING YEAR
This is the year of the final test of the unit.
VOLTAGE/PHASE/FREQUENCY
Electric alimentation characteristics.
MAX. CONSUMPTION(I max)
This is electrical current consumed by the unit during the limit working conditions.
INSTALLED POWER(P max)
It is the power absorbed by the unit during the limit working conditions.
PROTECTION
As defined by the EN 60529 European standard .
REFRIGERANT
This is the refrigerant fluid in the unit.
REFRIGERANT QUANTITY
This is the quantity of refrigerant fluid contained in the unit.
For TAEevo 015÷031 models
MAX. COOLING PRESSURE
This is the design pressure of the refrigeration circuit.
MAX. COOLING TEMPERATURE
This is the design temperature of the refrigeration circuit.
For TAEevo 051 models and upper models
MAX. COOLING PRESSURE HP SIDE
This is the design pressure of the refrigeration circuit of the high pressure side
MAX. COOLING PRESSURE LP SIDE
This is the design pressure of the refrigeration circuit of the low pressure side
USER CIRCUIT FLUID
Fluid used by the unit (normally water).
MAX. UTILIZATION PRESSURE
Max. designed pressure of the utilization circuit.
MAX. TEMPERATURE
Design temperature of the user circuit; this should not be confused with the maximum
working temperature which is established when the offer is made.
CONDENSER COOLING FLUID
Fluid the machine uses to cool the condenser.
MAX. WORKING PRESSURE
Maximum design pressure of the condenser cooling circuit.
MAX. TEMPERATURE
Maximum designed temperature of the cooling circuit of the condenser.
SOUND PRESSURE LEVEL
Sound pressure level in a free field in hemispherical irradiation conditions (open field)
at a distance of 1 m from the machine, condenser side, and at 1.6 m from the ground.
AMBIENT TEMPERATURE
Min. and max. cooling air temperature value.
WEIGHT
This is the approximate weight of the unit before packing.
Table 3 D
ATA PLATE AND MEANING OF ABBREVIATIONS
