Eachwheel hasa heightadjustmentlevertochange
thecuttingheightofthemower.Tochangethe height
ofcut,squeezeadjusterlevertowardthewheel,
movingup ordownto selectedheight.SeeFigure5.
.
6. Toassemblethe grasscatcher:
a. Placebagoverframe(blackplasticside is the
bottomofbag.)Insertthehookson the frame
throughtheholesinthesideplasticchannelsof
thebag.SeeFigure6.
b. Securebagtoframebyworkingtheplastic
channelsonbagoverframeasshownin Figure6.
All of the plasticchannelsexceptcentertopof bag
attachfromtheoutsideofbag.Centertopofbag
attachesfromtheinsideofbag.
7. AttachingGrassCatcherto Mower
a. Liftthereardischargedooronthemower,and
placethegrasscatcheron the pivotrod. Let go
ofdischargedoorsothat it restson thegrass
catcher. SeeFigure7.
__k ARNING: Never operate mower
unless the hooks on the grass
catcher are firmly seated on the
pivot rod, and the rear discharge
door rests firmly against top of
the grass catcher.
8. To removegrasscatcherandutilizethe mulching
feature:
Liftreardischargedooronthemowerasshownin
Figure7. Liftgrasscatcherupandout,off of the
pivotrod. Releasereardischargedoortoallowit
toclose rearopeningof mower.
a.
Figure 6
k,_ j
Figure 7
" t
Adjus merits
NOTE: Make certain
bag isturnediight
sideout be!ore
assembling (wamir
label will be on the
outside):
NOTE:Make certain
cablesarerouted
tothe outsideof the
handle s0 theYare
not in the wayWhen
attachingthe grass
catcherl
WARNING
Never operate mower
unless the hooks on
the grass catcher are
firmly seated on the
pivot to& and the
rear discharge door
rests firmly against
top of the grass
catcherl
