15
REF.
NO.
PART
NO. DESCRIPTION
1 710-04071 Splined Carriage Screw, 5/16-18 x 1.0
2 710-3015 Hex Cap Screw, 1/4-20 x.75
3 712-3068 Hex Lock Nut, 5/16-18
4 731-0851A Chute Flange Keeper
5 731-0915C Lower Chute, 5.0
6 731-0921 Upper Chute, 5.0
7 736-0159 Washer, .349 x .879 x .063
8 720-0284 Wingnut Knob, 5/16-18
9 710-1268 Screw, #10-16 x .375
10 712-3027 Hex Flange Lock Nut, 1/4-20
11 710-0451 Carriage Bolt, 5/16-18 x .75
12 726-0100 Push Cap, 3/8
13 720-0201A Knob, 1.0 x 3.2
14 731-1765 Shroud, Black—Models E162 & E172
15 735-0234 Rubber Grommet, .44 x .94 x .50
16 736-0185 Flat Washer, .375 x .738 x .063
17 714-0104 Internal Cotter Pin, .072 x 1.12
18 736-0451 Saddle Washer, .320 x .93
19 747-0697 Eyebolt, .70
20 747-0737 Upper Chute Crank
21 750-0785 Spacer, .382 x .50 x 1.12
22 712-3010 Hex Nut, 5/16-18
23 714-0507 Cotter Pin, 3/32 x .75
24 715-0138 Rolled Pin, 1/8 x .63
25 684-0126 Chute Crank Assembly
26 749-0705 Upper Handle
27 747-0946 Auger Bail (Control Handle)
28 749-0796B Lower Handle
29 736-0119 Lock Washer, 5/16
30 731-1087A Shroud, Black—Models 150 & E150
31 736-0400 Flat Washer, .194 x .62 x .063
32 731-0702 Shroud, Black—Model 140
33 710-1003 Screw, #10-16 x .625
34 747-0956 Auger Bail (Control Handle), Gullwing-style
35 749-0711A Upper Handle, Gullwing-style
— 720-0295 Foam Grip, 22” (not included with handle)
36 725-0157 Cable Tie
37 746-0883 Control (Cable) Housing
38 712-0324 Nylon Hex Lock Nut, 1/4-20
39 710-1270 Machine Screw, 1/4-20 x 1.31
40 710-0487 Carriage Screw 5/16-18
Models 140, 150, E150, E162 & E172
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
