MTD 140 - Page 17

17
REF.
NO.
PART
NO. DESCRIPTION
1 684-0054A Dash Assembly—Model E162
(Includes Plastic Cup for Mitten Grip)
684-0056 Dash Assembly—Model 140
(Includes Plastic Sleeve for Starter Rope)
684-0160 Dash Assembly—Model 150, E150, E172
(Includes Plastic Sleeve for Starter Rope)
2 750-0589 Spacer, .325 x .625 x .88—Model 140
3 710-1003 Screw, #10-16 x .625
4 710-1090 Hex Flange Screw, 5/16-18 x 1.25
5 710-1268 Screw, #10-16 x .375
6 710-1652 Self-tapping Screw, 1/4-20 x .625
7 712-3010 Hex Nut, 5/16-18
8 754-0101A Drive Belt—Model 150, E150, E162, E172
754-0367 Drive Belt—Model 140
9 756-0416B Pulley Half-.625 x 2.25
10 756-0475 Auger Drive Pulley
- 756-0550 Auger Drive Pulley-Model 140 Series Only
11 734-1176 Wheel Assembly, 7 x 1.5
12 725-0201 Ignition Key
13 725-1341B Ignition Key w/ Plastic Cover
14 725-1346 Ignition Nut, 5/8-32—Model E162, E172
712-0252 Jam Nut, 5/8-32—Model 140, 150, E150
15 725-1347 Ignition Switch Cap
16 725-1425 Ignition Switch
17 784-5178A Chute Crank Bracket—Model 140
18 731-1089A Choke Cover
19 731-1133C Spark Plug Cap
20 7510009630 Recoil Handle (Standard)
21 751-0535 Fuel Line Hose
22 736-0119 Lock Washer, 5/16
23 750-0716 Spacer, .630 x .88 x .680
24 736-0225 Internal Lock Washer, 5/8 x 1.058 x .046
25 751-0352 Gas Tank, 1 qt—Model 140
26 751-0353 Fuel Cap for 751-0352
27 751-0540A Gas Tank, 2 qt.—Model 150, E150,
E162, E172
28 751-0800 Fuel Cap for 751-0540A (50:1 Red Print)
29 7510009636 Recoil Handle (Mitten Grip)
30 723-0354 Primer Tube
31 751-0354 Primer Bulb
32 684-0114B Auger Housing Assembly
33 710-0167 Screw, 1/4-20 x .50
34 710-0191 Cap Screw, 3/8-24 x 1.25
35 710-0323 Trus Machine Screw, 5/16-18 x .75
36 710-0352 Hex Index Washer Screw, 1/4-14 x .375
37 710-0451 Carriage Bolt, 5/16-18 x .75
38 710-0642 Self-tapping Screw 1/4-20 x .75
39 710-0773 Self-tapping Screw 3/8-16 x .50
40 710-0896 Self-tapping Screw, 1/4-14 x .625
41 710-1005 Self-tapping Screw, 1/4-14 x .50
42 710-0848A Axle, .35 x .5 x 20.75
43 712-0116 Jam Lock Nut, 3/8-24
44 712-3027 Hex Flange Lock Nut, 1/4-20
45 784-5177 Engine Support Bracket—Model 140
46 731-1033 Shave Plate, 2.66 x 19.88
47 732-0357A Extension Spring, .33 x 1.12
48 736-0108 Flat Washer, .51 x .75 x .033
49 736-0176 Flat Washer, .265 x .938 x .120
50 736-0242 Belleville Washer, .340 x .872
51 736-0326 Flat Washer, .51 x 1.0 x .125
52 736-0329 Lock Washer, 1/4
53 741-0475 Plastic Bushing
54 741-0600 Ball Bearing, 17mm x 40mm x 12mm
55 746-0910A Cable, 41.78” (includes end spring)
56 748-0234 Shoulder Spacer
57 726-0205 Hose Clamp, .49
58 741-0475 Plastic Bushing, .38
59 756-0313 Flat Idler Pulley, 1.88 x .50 x 2.12
60 710-0895 Hi-Lo Self-tapping Screw, 1/4-15 x .75
61 784-5174 Bearing Cup
62 784-5175B Brake Idler Bracket
63 784-5176 Belt Cover
64 784-5485 Solid Shaft Auger Assembly
65 784-5720 Chute Crank Bracket
66 629-0236 110V Extension Cord, 2-prong
67 705-5139A Fuel Tank Support Bracket—Model 150,
E150, E162 & E172
68 710-0157 Hex Cap Screw, 5/16-24 x .75
69 710-3013 Hex Cap Screw, 1/4-20 x .50
70 710-3025 Hex Cap Screw, 5/16-24 x .625
—Model 150, E150, E162, E172
710-0805 Hex Cap Screw, 5/16-18 x 1.50
—Model 140
71 726-0152 Self-adhesive Clamp, .5 (for starter cable)
72 731-0782 Rubber Paddle
73 731-0780A Rubber Paddle/Spiral
74 784-5344 Chute Crank Assembly—Model 140
REF.
NO.
PART
NO. DESCRIPTION
Models 140, 150, E150, E162 & E172
NOTE: Snow thrower features/components vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
IMPORTANT: For a proper
working machine, use
Factory Approved Parts.
V-belts are designed to
engage and disengage
safely. A substitute (non
OEM) V-belt can be
dangerous by not
disengaging completely.
