MTD 190-116 - Page 5

5
Figure 5
Left-hand Skirt Segment
Right-hand Skirt Segment
Make Sure that the deck segments
butt flushly up against each other.
Make Sure that the RH skirt segment
butts flushly up against the toe guard.
Toe Guard
IMPORTANT: Line up the deck skirts evenly along the edge of the cutting deck’s front lip.
38-inch Decks
