MTD 225 - Page 15

15
Model Series 300 & 330
Ref.
No.
Part No. Part Description
1. 720-0274 Grip
2. 731-0473 Clutch Grip
3. 686-0002 Clutch Lever
4. 649-0137 Handle Assembly
5. 712-0442 Lock Nut Cap 1/4-20
6. 738-1225 Shoulder Screw
7. 746-1148 Clutch Cable
8. 738-1226 Shoulder Screw
9. 710-0189 Hex Cap Screw 5/16-18 x 3.0
10. 736-0242 Bell Washer .340 ID x .872 OD
11. 786-0340 Adjustable Handle Crank
12. 710-0606 Hex Cap Screw 1/4-20 x 1.5
13. 719-0279 Rope Guide
14. 712-0720 Flange Nut 5/16-18
15. 786-0341 Retainer Bracket
16. 649-0136 Handle Tube
17. 710-0805 Hex Cap Screw 5/16-18 x 1.5
18. 711-0415 Clevis Pin 3/8 x 1.62
19. 750-0890 Spacer
20. 786-0003 Tailpiece Bracket LH
21. 786-0004 Tailpiece Bracket RH
22. 786-0005 Depth Bar
23. 714-0149B Cotter Pin
24. 712-3004A Hex Flange Locknut 5/16-18
25. 712-3010 Hex Nut 5/16-18
26. 710-3180 Hex Cap Screw 5/16-18 x 1.75
27. 710-0604A Hex Washer Screw 5/16-18 x .625
28. 710-0602 Hex Washer Screw 5/16-18 x 1.0
29. 738-0934 Shoulder Screw
30. 712-0240 Jam Nut 7/16-20
31. 736-0171 Lock Washer 7/16
32. 786-0138A Frame RH
33. 786-0139A Frame LH
34. 712-3004A Flange Lock Nut 5/16-18
35. 711-0919 Belt Cover Belt
36. 710-0599 Hex Washer Screw 1/4-20 x .500
37. 786-0035A Tine Shield 20”
38. 710-0502A Hex Washer Screw 3/8-16 x 1.25
39. 710-3008 Hex Cap Screw 5/16-18
40. 786-0053 Tine Shield Bracket 20”
41. 786-0337 Tine Shield 18”
42. 786-0039B Cover Bracket
43. 736-0119 Lock Washer 5/16
44. 710-0107 Hex Cap Screw 5/16-24 x .50
45. 750-0892 Input Spacer .64 ID x 2.4 Lg
46. 748-0350 Pulley Adapter
47. 756-0971 Engine Inner Half Pulley
48. 756-0972 Engine Outer Half Pulley
49. 754-0428 Belt
50. 736-0452 Bell Washer .396 ID x 1.140 OD
51. 710-0152 Hex Cap Screw 3/8-24 x 1.0
52. 756-0585 Flat Pulley
53. 736-0312 Retainer Bearing Washer
54. 736-0112 Spherical Washer .531 ID x .620 OD
55. 712-3029 Jam Nut 1/2-20
56. 710-0599 Hex Washer Screw 1/4-20 x .50
57. 786-0056 Cover Belt
58. 712-0392 Lock Nut Cap 1/4-28
59. 736-3020 Flat Washer .271 ID x .630 OD
60. 738-0930 Shoulder Screw
61. 712-0266 Jam Nut 3/8-16
62. 786-0144 Idler Bracket
63. 786-0149 Idler Keeper Bracket
64. 756-0313 Flat Idler
65. 710-0723 Hex Cap Screw 3/8-16 x 1.25
Ref.
No.
Part No. Part Description
