MTD 225 - Page 17

17
Model Series 300
Ref.
No.
Part No. Part Description
1. 734-1988 Wheel 7 x 1.8
2. 738-0929 Shoulder Screw
3. 686-0081A Wheel Bracket Assembly
4. 714-0149B Cotter Pin
5. 711-0415 Clevis Pin
6. 736-0242 Bell Washer .340 ID x .872 OD
7. 710-0189 Hex Cap Screw 5/16-18 x 3.0
8. 738-0934 Shoulder Screw
9. 750-0273 Spacer .51 ID x .69 OD x 1.97Lg
10. 750-0470 Spacer .47 OD x .96Lg
11. 686-0189 Chain Case Assembly
12. 712-0429 Hex Lock Nut 5/16-18
13. 736-0171 Lock Washer 7/16
14. 712-0240 Jam Nut 7/16-20
15. 04922 Tine Blade 9.5” RH
16. 04923 Tine Blade 9.5” LH
17. 711-0702 Clevis Pin
18. 710-0599 Hex Washer Screw 1/4-20 x .50
19. 750-0456 Spacer .790 ID x .347 Lg
20 04918 Tine Adapter Assembly
Ref.
No.
Part No. Part Description
