Model Series 410
NOTE: For painted parts, please refer to the list of color codes below. Please add the applicable color code, wherever needed,
to the part number to order a replacement part. For instance, if a part numbered 700-xxxx is painted Oyster Gray, the part
number to order would be 700-xxxx-0662.
Black — 0691; Black, Powder — 0637; Blue, Midnight — 0667; Charcoal — 0483; Grey — 0648;
Grey, Oyster — 0662; Orange — 0606; Red — 0650; Red, MTD — 0638; Silver — 0629; Yellow — 0674.
Ref.
No.
Part No. Part Description
1. 710-1017 Tap Screw 1/4-14 x.625
2. 786-0131 Handle Cover w/o Throttle
3. 710-0896 Hex Washer Screw 1/4-14 x.625
4. 720-0278A Foam Grip
5. 735-0246A End Plug
6. 647-0014 Clutch Control Assembly
7. 786-0118 Return Bracket - LH
8. 786-0098 Return Bracket - RH
9. 649-0017 Handle Assembly
10. 720-0210A Knob
11. 712-3008 Jam Nut 3/8-16
12. 726-0330 Cable Clip
13. 747-0902 Shift Control
14. 735-0127 Rubber Washer.33 ID x.87 OD
15. 714-0104 Cotter Pin
16. 736-0204 Flat Washer.344 ID x.62 OD
17. 712-04063 Hex Flange Lock Nut 5/16-18
18. 784-0191 Retainer Bracket
19. 712-0379 Flange Lock Nut 3/8-24
20. 750-0885A Spacer.322 ID x.625 OD
21. 784-0190 Handle Adjustment Crank
22. 710-0189 Hex Screw 5/16-18 x 3.0
23. 786-0109 Handle Mounting Bracket - LH
24. 786-0108 Handle Mounting Bracket - RH
25. 726-0106 Cap Nut
26. 747-0432 Rod
27. 786-0113 Rear Tine Shield Flap
28. 710-3005 Hex Cap Screw 3/8-16 x 1.25
29. 736-0117 Flat Washer.375 ID x.620 OD
30. 710-3008 Hex Cap Screw 5/16-18 x.75
31. 738-0849 Hex Screw 5/16-18 x.75
32. 786-0085 Tine Shield
33. 712-0421 Wing Nut
34. 686-0044A End Cover Assembly
35. 786-0090 Side Shield
36. 786-0076 Shield Bracket RH
37. 710-0376 Hex Cap Screw 5/16-18 x 1.0
38. 736-0169 Lock Washer 3/8
39. 711-0415 Clevis Pin
40. 712-3017 Hex Nut 3/8-16
41. 710-3038 Hex Cap Screw 5/16-18 x.875
42. 686-0043A Tine Shield Bracket Assembly
43. 786-0120 Depth Stake
44. 786-0077 Shield Bracket - LH
45. 710-3097 Carriage Bolt 3/8-16 x 1.0
46. 714-0147 Cotter Pin
47. 746-0916 Clutch Cable
Ref.
No.
Part No. Part Description
To Next Page
