MTD 41M User Manual

25
Ref
No.
Part Number Description
1. 747-1161A Blade Control
2. 749-1092A Upper Handle
3. 710-1205 Rope Guide
4. 720-0279 Wing Nut, 1/4-20
5. 710-1174 Carriage Bolt, 5/16-18 x 2
6. 720-04072 Hand Star Knob
7. 749-0928A Lower Handle
8. 712-0397 Wing Nut, 1/4-20
9. 746-04299 Control Cable
10. 726-0240 Cable Tie
11. 664-04007A Grass Bag
12. 747-04080A Grass Bag Frame
13. 732-04089A Torsion Spring LH
14. 731-05642 Trailshield
15. 747-04587 Rear Door Pivot Rod
16. 710-0654A TT Screw, 3/8-16 x 1
17. 731-05865 Rear Discharge Door
18. 731-04150C Rear Baffle
19. 732-04090A Torsion Spring RH
20. 710-1241 Screw, 1/4-15 x 1.00
21. 787-01276 Deck 21 inch
22. 687-02271A Handle Bracket Assy - RH
687-02270A Handle Bracket Assy - LH
23. 687-02099B Ht. Adj. Assy. Frt - LH
687-02100B Ht. Adj. Assy. Frt - RH
Ref
No.
Part Number Description
24. 782-5002B Front Baffle
25. 748-0377C Blade Adapter, #6 x 2.15 w/Star
26. 742-0741 Mulch Blade
27. 736-0524B Blade Bell Support
28. 710-1257 Screw, 3/8-24 x 2.50
29. 712-04065 Flange Lock Nut, 3/8-16
30. 787-01290 Height Adjustment Plate
31. 687-02338 Pivot Arm Assy - RH
687-02337 Pivot Arm Assy - LH
32. 734-1988 Front Wheel, 7 x 1.8
33. 738-04266 Scr., Shldr., .500 Dia. X .385
34. 732-0404 Spring Lever
35. 720-0426 Height Adjustment Knob
36. 687-02333 Pivot Arm Assembly - RH
687-02332 Pivot Arm Assembly - LH
37. 732-04175 Spring Lever
38. 710-0703 Carriage Bolt, 1/4-20
39. 734-1987 Rear Wheel, 8 x 1.8
40. 710-1652 Screw, 1/4-20 x .625
41. 710-0606 Screw, 1/4-20 x 1.50
42. 712-04064 Nut, Flglk., 1/4-20
43. 746-04239A Choke Cable
44. 731-05400 Engine Shroud
45. 710-04577 Screw, Mach., M4-.7
