MTD 640 - Page 17

17
Model 640
REF.
NO.
PART
NO. DESCRIPTION
1 625-0007 Light Ass’y, Top Mount
2 684-0008A Shift Arm Ass’y.
3 705-5204A Chute Crank Ass’y.
4 684-0036 Handle Ass’y - Engagement R.H.
5 684-0037 Handle Ass’y - Engagement l.H.
6 684-0103 Handle Panel Ass’y
7 710-0458 Carriage Bolt 5/16-18 x 1.75”
8 710-0276 Carriage Screw 5/16-18 x 1.0”
9 710-0449 Carriage Screw 5/16-18 x 2.25”
10 710-0451 Carriage Bolt 5/16-18 x .75”
11 710-0459A Hex Head Screw 3/8-24 x 1.5”
12 710-0599 Hex Washer Screw 1/4-20 x .50”
14 710-1003 Hex Washer Screw #10-16 x .625”
15 710-1880 Hex Cap Screw 5/16-18
16 710-3015 Hex Cap Screw 1/4-20 x .75”
17 711-0653 Clevis Pin
18 711-0677 Ferrule
19 712-0116 Jam Nut 3/8-24
20 712-0121 Nut #10-24
21 712-0271 Hex Nut 1/4-20
22 710-0788 Hex Washer Screw 1/4-20 x 1.0
23 712-3010 Hex Nut 5/16-18
24 712-3027 Flange Lock Nut 1/4-20
25 714-0507 Cotter Pin
28 720-0201A Chute Crank Knob
29 720-0232 Knob, Shift
30 720-0274 Grip
31 720-0284 Wing Nut
32 726-0100 Push Cap
33 731-0851A Chute Flange Keeper
34 731-0921 Upper Chute
35 731-1300A Lower Chute
36 731-1393 Handle Panel
37 732-0145 Compression Spring
38 732-0193 Compression Spring
39 732-0746 Torsion Spring
40 735-0199A Bumper, Rubber
41 736-0105 Bell Washer .401 x .870
42 712-3068 Hex Nut 5/16-18
43 736-0159 Washer .349 ID x .879 OD
44 736-0185 Flat Washer .375 ID x .738 OD
45 736-0119 Bell Washer .340 ID x .872 OD
46 736-0275 Flat Washer .344 ID x .688 OD
48 736-0451 Saddle Washer .320 ID x .93 OD
49 736-0509 Washer, Spec
51 735-0234 Rubber Grommet
52 746-0778 “Z” Fitting
53 747-0620A Upper Shift Rod
54 747-0621 Lower Shift Rod
55 747-0877 Rod, Cam
56 748-0362 Cam Handle
57 748-0363 Pawl, Handle Lock
58 749-0951 Lower Handle
59 749-0952A Upper Handle RH
60 749-0953A Upper Handle LH
61 750-0963 Clutch Rod Connector
62 784-5619A Shift Handle
63 747-0697 Eyebolt Chute Crank
64 784-5679 Handle Support Bracket LH
65 784-5680 Handle Support Bracket RH
66 784-5681 Handle Support Bracket LH
67 784-5682 Handle Support Bracket RH
68 710-0643 Hex Bolt 5/16-18 x 1.0”
69 712-0429 Lock Nut
REF.
NO.
PART
NO. DESCRIPTION
