12
4
Operating
Your Lawn
Tractor
Know Your Lawn Tractor
Figure 8
A Speed Control Lever/ Parking Brake E Throttle Control Lever
B Clutch-Brake Pedal F Ignition Switch Module
C Shift Lever G Deck Lift Lever
D Choke Control† H PTO (Blade Engage) Lever
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
† If so equipped
NOTE: Any reference
in this manual to the
RIGHT or LEFT side of
the tractor is observed
from operator’s position.
NOTE: Steering wheel not shown for clarity
