Illustrated
Parts List
Ref.
No.
Part No. Description
1 17962 Plate, Switch
2 647-04040 Handle Asswmbly, PTO
3 710-0224 Screw, #10-16, 0.500
4 710-0599 Screw, 1/4-20, 0.500
5 710-3157 Screw, 7/16-20, 3.25, Gr5
6 714-0104 Pin, Cotter, .072 Dia. x 1.13
7 714-0145 Pin, Click, .092 x 1.64
8 720-04049 Grip, Handle, 3/8
9 732-04276 Spring, Extension
10 736-0171 Washer, Lock, 7/16
11 736-0300 Washer, Flat, .406 x .875 x .059
12 736-0322 Washer, Flat, .450 x 1.250 x .164
13 741-04119 Bearing, PTO
14 746-04173A Cable, Deck Engagement
15 783-04753 Frame Support Bracket
16 756-04196 Engine Pulley, 3.39 x 6.12 Dia.
17 725-04039 Switch, Interlock
18 747-04332A Rod, Belt Keeper (38-inch Deck)
747-04307 Rod, Belt Keeper (42-inch Deck)
19 710-1260A Screw, 5/16-18, .750
20 683-04163A Frame Assembly
21 710-0642 Screw, 1/4-20, 0.750
22 710-0604A Screw, 5/16-18, 0.625
23 712-04064 Nut, Flange Lock, 1/4-20, GrF
24 732-04035 Spring, Compr. , 1.28 OD x 3.125
25 736-0222 Washer, Lock, 1/4
26 747-04385 Hold Down Rod, Battery
Ref.
No.
Part No. Description
27 783-04869 Bracket, Battery
28 783-04548A Seat Bracket, Frame
29 783-04637 Bracket, Runing Board
30 725-1426A Solenoid
31 683-04155 Shaft Assembly, Lift
32 712-04065 Nut, Flange Lock, 3/8-16, GrF
33 714-04043 Pin, Cotter, .080 x 1.5625 Internal
34 716-0106A Ring, E-Type, .625 Dia.
35 720-0311 Grip, Handle, 1/2
36 732-04225 Spring, Torsion
37 738-04130 Screw, Shldr. , .625 x .175, 3/8-16
38 741-0225 Bearing, Hex Flange
39 747-04393 Rod, Lift
40 747-04282 Deck Handle, Lift
41 783-04494 Lift Arm, Deck - RH
783-04711 Lift Arm, Deck - LH
42 710-0703 Screw, Carriage, 1/4-20, .75, Gr5
43 712-0271 Nut, Sems, 1/4-20
44 725-1737A Battery, 190 CCA
725-1704A Battery, 125 CCA
45 683-04195 Support Bracket Assembly
46 710-0134 Carriage Screw, 1/4-20 x .62
47 710-3025 Screw, 5/16-18 x .625
48 712-04063 Flange Lock Nut, 5/16-18
49 712-0429 Hex Lock Nut, 5/16-18
50 736-0173 Flat Washer, .28 x .74 x .063
To order replacement
parts, call the Customer
Service Line at
1-800-800-7310,
or visit
www.mtdproducts.com.
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
