MTD 765 - Page 21

21
10
Illustrated
Parts List
Ref.
No.
Part No. Description
1 710-0227 Screw, #8-18 x .50
2 710-1502 Screw, #8-18 x .375
3 710-0726 Self-tapping Screw, 5/16-12, .75
4 710-1237 Screw, #10-32, .625
5 710-1314A Socket Cap Screw, 5/16-18, .625
6 710-1315 Self-tapping Screw, 3/8-16, 1.25
7 751-10013 Exhaust Pipe
8 783-04573 LH Muffler Bracket
9 725-0157 Cable Tie, 7.4”
10 726-0205 Hose Clamp, .490
11 710-0599 Screw, 1/4-20, 0.500
12 751-9986A Muffler, Bug
13 783-04574 RH Muffler Bracket
14 751B221535 Casing Clamp
15 751-10349 Fuel Line Hose
16 751-0564B Muffler Deflector
17 751-10162 Muffler, Single Inlet
18 783-04576 Muffler Shield
Ref.
No.
Part No. Description
19 751-0620A Exhaust Pipe
20 751-3140 Oil Drain Valve
21 751-3141 Oil Drain Hose
22 751-3142 Oil Drain Cap
23 783-0615D Muffler Heat Shield
24 721-0348 Exhaust Gasket
25 731-1682A Oil Drain Sleeve
26 751-0617B Muffer, Single Inlet
27 721-0208 Exhaust Gasket
28 737-0143 Oil Drain Cap, 3/8-18
29 737-0199 Oil Drain Pipe, 3/8-16, 2.0
30 712-04065 Flange Lock Nut, 3/8-16
31 751-0619A Exhaust Pipe
32 751B222261 Muffler Deflector
33 736-0300 Flat Washer, .406 x .875 x .059
34 738-0143 Shldr Screw, .498 x .340 x 3/8-16
35 751-0622A Exhaust Pipe
36 712-0271 Hex Sems Nut, 1/4-20
To order replacement
parts, call the Customer
Service Line at
1-800-800-7310,
or visit
www.mtdproducts.com.
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
(a) Tractor models with Tecumseh Single-cylinder Engine (16 HP - 18 HP)
(b) Tractor models with Tecumseh Single-cylinder Engine (12 HP - 15 HP)
(c) Tractor models with Briggs and Stratton OHV Single-cylinder Engine
(d) Tractor models with Briggs and Stratton OHV Single-cylinder Engine (canister mufffler)
