Illustrated
Parts List
Ref.
No.
Part No. Description
1 617-04024 Gear Assembly, Steering
2 710-0376 Screw, 5/16-18, 1.00, Gr5
3 710-0643 Screw, 5/16-18, 1.00, Gr5, Lock
4 710-1309 Screw, Mach, 5/16-18, 0.750
5 710-3180 Screw, 5/16-18, 1.75, Gr5
6 712-0240 Nut, Jam, 7/16-20, Gr2
7 712-0262 Nut, Jam Lock, 3/8-24, Gr2
8 712-04063 Nut, Flange Lock, 5/16-18, Grf
9 731-0484A Hub Cap
10 723-0448A Ball Joint, 7/16-20, Lock
11 736-0242 Washer, Bell, .340 x .872 x .060
12 783-04568 Front Hanger Bracket, Deck
13 738-04141 Scr., Shlder, .435 x .3485, 5/16-18
14 738-0919 Steering Shaft, 5/8 Spline x 21.86
15 741-04124 Bearing, Flange, Hex 5/8
16 741-0475 Plastic Bushing .380 ID
17 747-04298 Drag Link, Steering
18 748-0389 Cap, 1.25 x .16
19 748-04065 Steering, Block
20 748-04068 Spacer, .710 ID x .125 OD x .56
21 750-04418 Spacer, .322 ID x .625 OD x .21
22 783-04644 Stabilizer Plate, Gear Segment
23 638-04007 Axle Assembly, LH
24 638-04008 Axle Assembly, RH
25 683-0128B Pivot Bar
Ref.
No.
Part No. Description
26 710-0726 Screw, 5/16-12, 0.750
27 712-04065 Nut, Flange Lock, 3/8-16, GrF
28 714-04039 Pin, Cotter, 5/32, 1.25
29 714-0470 Pin, Cotter, 1/8 x 1.25
30 726-0341 Push Cap, 3/4
31 731-04057A End Cap, Pivot Bar (Standard)
731-1291A End Cap, Pivot Bar (w/ Fitting)
32 736-0316 Washer, Flat, .78 x 1.59 x .060
33 738-04128 Scr., Shlder, .500 x 2.380, 3/8-16
34 741-0660A Bearing, Flange, .760 x .941 x 1.0
35 747-04299A Tie Rod
36 783-04601B Bracket, Pivot
37 731-04057A Axle End Cap, Standard
38 631-04028 Steering Wheel, Standard Grip
631-04008 Steering Wheel, Soft Grip
39 731-04039 Cap, Steering Wheel (no logo)
731-04040 Cap, Steering Wheel (sprig logo)
731-04681 Cap, Steering Wheel (tine logo)
40 634-04229 Wheel Ass’y, Round Shoulder
734-0864 Tire Only, 15 x 6 x 6, Round Shld.
634-04086 Wheel Ass’y, Square Shoulder
734-1731 Tire Only, 15 x 6 x 6, Square Shld.
634-04081 Rim Assembly (Incl. bearings and
valve stem)
To order replacement
parts, call the Customer
Service Line at
1-800-800-7310,
or visit
www.mtdproducts.com.
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard
equipment.
