MTD 830 Series - Parts List

17
8
Parts List
To order replacement
parts, contact
1-800-800-7310
or visit
www.mtdproducts.com
† Equipped with Electric Start Units
†† Equipped on Units with Briggs & Stratton Engine
‡ Equipped on Units with Honda Engine
* If Equipped
Ref.
No.
Part No. Description
1 746-04265A Drive Cable
2 735-04059 Rubber Grommet
3 753-05096A Drive Control Assembly
4 731-04859* Bail Cover
5 747-1161A Blade Control
6 746-04213 Control Cable
7 749-04037 Lower Handle
8 725-0157 Cable Tie
9 732-04265 Torsion Spring, LH
10 710-0599 TT Screw, 1/4-20 x .500
11 787-01341A 21-inch Deck
12 710-0654A TT Screw, 3/8-16 x 1.00
13 787-01346 Front Deck Baffle
14 756-04157B†† Upper Engine Pulley
756-04273‡ Upper Engine Pulley
15 756-04156B†† Lower Engine Pulley
756-04272‡ Lower Engine Pulley
16 736-0514†† Flat Wash., .885 x 1.850 x .060
17 748-0376C†† Blade Adapter
748-04096‡ Blade Adapter
18 710-1044 Screw, 3/8-24 x 1.50
19 736-0524B Blade Bell Support
20 742-0741 21” Mulching Blade
21 736-0513†† Sprg Washer, .890 x 1.70 x .048
22 750-1071†† Sleeve Spacer, .88 x 1.13 x .12
750-04818‡ Slv. Spcr., 25mm x 1.375 x .375
23 731-05903 Engine Baffle
24 731-05463A Deck Baffle
25 710-0260A Carriage Bolt, 5/16-18 x .62
26 712-04063 Flange Lock Nut, 5/16-18
27 731-05462A Trailshield
Ref.
No.
Part No. Description
28 731-05157 Mulch Plug
29 731-05017A Rear Door
30 710-1241 Screw, 1/4-15 x 1.00
31 720-04072 Star Knob
32 732-04264 Torsion Spring, RH
33 711-04374 Door Pivot Rod
34 647-04051 Grass Catcher Frame
35 664-04052A Grass Catcher - Gray
664-04046A Grass Catcher - Black
36 710-1174 Carriage Bolt, 5/16-18 x 2.00
37 720-0279 Wing Nut
38 710-1205 Eye Bolt
39 749-04209† Upper Handle
749-04206 Upper Handle
40 736-0270 Bell Washer, .265 x .75 x .062
41 732-1014 Torsion Spring
42 17032A Chute Deflector Adapter
43 747-0710 Hinge Pin
44 687-02055 Mulch Plug Assembly
45 731-04177 Side Discharge Chute
46 725-04323† 12 Volt Battery
47 725-04329† Battery Charger
48 726-0240† Cable Tie
49 728-0199† Rivet
50 725-04347† Key Switch
51 725-0201† Key
52 625-04029† Electric Starter Harness Ass’y.
53 710-1667A† Screw, #10-16 x .750
54 750-04825‡ Sleeve Spacer
55 736-0447‡ Washer, Wave, 1.5 x 1.0 x .029
