Parts List
IMPORTANT
For a proper working
machine, use Factory
Approved Parts.
V-BELTS are specially
designed to engage
and disengage safely.
A substitute (non OEM)
V-Belt can be danger-
ous by not disengaging
completely.
To order replacement
parts, contact
1-800-800-7310
or visit
www.mtdproducts.com
Ref.
No.
Part No. Description
1 754-04093 V-Belt
2 732-04338 Spring Lever
3 720-0230 Foam Grip
4 717-04184A Spur Gear, 14T - LH
5 710-0599 TT Screw, 1/4-20 x 0.50
6 750-04305A Spacer
7 749-04267A Cross Bracket
8 687-02204 Front Bracket Assembly
9 731-05470 Clip Spacer
10 741-04136B Split Hex Flange Bearing
11 734-04033 Front Wheel
12 712-04065 Flange Lock Nut, 3/8-16
13 634-04207D Rear Wheel
14 710-04531 Screw, 1/4-20 x .39
15 717-04192A Spur Gear, 14T - RH
16 736-3084 Flat Washer
17 782-7551A Wheel Dust Cover
18 748-04159 Transmission Bearing Support
19 750-04317 Clip Spacer
20 716-0198 Retaining Ring .875
21 687-02314 Rear Bracket Assembly
22 732-0320 Extension Spring
23 756-04151A Pulley, 3.36 OD
24 736-0105 Bell Washer, .375 x .870 x .063
25 712-0411 Hex Lock Nut, 5/16-24
26 687-02205 Handle Bracket Assembly LH
27 715-0221 Dowel Pin
28 618-04378 Transmission Assembly
29 687-02206 Handle Bracket Assembly RH
30 748-0390 Bearing Support Spacer
31 736-0504 Washer, Wave, .510 x .750 x .017
