Deck and Transmission
37
7. Ease the front axle back into a postition that com-
pletely relaxes the lift assist spring.
8. Remove the front axle retainers using a 3/8” wrench.
See Figure 4.26.
9. With the retainers off, the axle will still be held in
place by two spring tabs on each end of the axle.
See Figure 4.27.
10. Press a socket or similar round tool into the gap
between each pair of tabs, gently spreading them to
release the axle. See Figure 4.28.
Figure 4.26
Front axle
Retainer
Figure 4.27
Spring tabs
Figure 4.28
