MTD ET 1000 - Decorative Trimming; Edging; Trimming Tips; 5. MAINTENANCE AND REPAIR INSTRUCTIONS

ET 1000
3
ENGLISH
n Entanglement with foreign matter
n Normal line fatigue
n Attempting to cut thick weeds
n Forcing the line into walls or
fenceposts
5. MAINTENANCE AND REPAIR INSTRUCTIONS
INSTALLING A NEW TRIMMING LINE
The trimming line may be replaced by two
methods - rewinding the existing reel or
installing a prewound reel.
REWINDING THE EXISTING REEL
To rewind the existing reel you must:
n Check for the correct line size.
n Remove the inner reel and spring.
n Wind the reel with the new line.
n Reinstall the existing reel and spring.
THE CORRECT LINE TO USE
Use a dual line reel with Ø 2,00 mm.
REMOVING THE EXISTING REEL
n Unscrew the Bump Knob
counterclockwise (
N
FIG. 10).
n Remove the inner reel (
N
FIG. 11).
n Use a clean cloth to clean the inside of
the outer spool (
N
FIG. 12).
n Check the indexing teeth on the reel and
spool for wear (
N
FIG. 13). If
necessary, replace the reel and spool.
WINDING THE EXISTING REEL
n Insert the ends of new trimming line into
the inner reel holes (
N
FIG. 14).
n Loop the line into two equal lengths
before inserting it into the holes.
n Wind the line, in even and tight layers
(
N
FIG. 15), onto the reel, and in the
direction indicated.
n Push the ends of the line into the
slots(
N
FIG. 16).
REINSTALLING THE REEL
n Insert the ends of the line through the
eyelets in the outer spool (
N
FIG. 17).
n Grasp the ends and pull firmly to release
the line from the slots in the spool.
n Install the Bump Knob clockwise (
N
FIG.
10).
Line installation is now complete.
INSTALLING A PREWOUND REEL
n Use the same instructions as the existing
reel:
n The Correct Line to Use;
n Removing the Existing Reel;
n Reinstalling the Reel.
CLEANING / STORAGE
n Do not block the air vents.
n Do not use strong detergents on the
plastic housing or handle.
n Moisture can cause a shock hazard.
Wipe off moisture with a soft cloth.
n Clean the unit thoroughly before storing.
Hang the unit by the handle loop and
store it in a dry, well-ventilated area, out
of the reach of children.
