SECTION 5: KNOW YOUR GARDEN TRACTOR
Figure 4
NOTE: Any reference in this manual to the RIGHT or LEFT side of the tractor is observed from operator’s position.
A PTO (Blade Engage) Knob G Brake Pedal
B Systems Indicator Monitor/Hour Meter H Drive Pedal
C Choke Control I Ignition Switch Module
D Parking Brake Lever J Cruise Control Lever
E Cup Holder K Deck Lift Lever
F Throttle Control
F
K
H
G
D
A
B
E
NOTE: Steering Wheel not shown for clarity.
J
C
I
