31
Model P805K
REF.
NO.
PART
NUMBER DESCRIPTION
1 17962 Plate, Switch
2 683-04173 Frame Assembly, Lower
3 683-04219 Bumper Assembly
4 710-0224 Screw, Hex Washer, 10-16 x .5
5 710-0726 Screw, Self-tapping, 5/16-18, 0.75
6 710-1260A Screw, Self-tapping, 5/16-12, 0.75
7 710-1652 Screw, Hex Washer, 1/4-20 x 0.625
8 711-0332 Pin, Clevis, .50 Dia x .78 Lg
9 712-04065 Nut, Nylon Lock, 3/8-16
10 710-0607 Screw, Hex Wash. Tapp, 5/16-18 x .5
11 714-04023 Pin, Internal Cotter
12 725-04039 Switch, Interlock
13 732-04035 Spring, Compression, 1.28 OD x 3.125
14 736-0222 Washer, Lock, Ext 1/4
16 738-04058 Shoulder Spacer
17 738-0143 Shoulder Screw, 3/8-16
18 710-3005 Hex Screw 3/8-16 x 1.25
19 783-0726E Bracket, Pivot, Support RH
20 783-0727D Bracket, Pivot, Support LH
21 783-0728 Bracket, Pivot, Bar
22 783-04811 Frame, Upper
23 783-04329A Bracket, Frame, Seat
24 712-04064 Nut, Nylon Lock, 1/4-20
25 710-0599 Screw, Self-tapping, 1/4-20, 0.500
26 725-1426A Solenoid, 12V, 100 Amp
27 736-0222 Washer, External Lock, 1/4
28 710-0642 Screw, Hex. 1/4-20 x .75
29 725-1750A Battery, 235 CCA
30 712-0324 Nut, Sems, 1/4-20
31 710-0703 Screw, Carriage, 1/4-20, .75,
32 747-04121A Hold-down Rod, Battery
33 783-0349 Tray, Battery
34 783-0693 Axle Bracket
35 731-05598 Bumper Cap
