MTD P805K - Page 37

37
REF.
NO.
PART
NUMBER DESCRIPTION
1 710-0599 Screw, 1/4-20, 0.500
2 710-0642 Screw, 1/4-20, 0.750
3 710-0726 Screw, 5/16-12, 0.750
4 710-0895 Screw, 1/4-15, 0.750
5 710-1017 Screw, 1/4-14, 0.625
6 710-1611B Screw, 5/16-18, 0.750
7 710-3217 Screw, Machine, #8-32, 0.375
8 712-0142 Nut, Hex, #8-32, Gra
9 731-04215 Dash Lever, Cruise
10 731-04217 Dash Lever, Brake
11 731-05005B Panel, Dash
12 731-1857 Knob, Control
18 736-0270 Washer, Bell, .265 x .75 x .062
19 747-1196 Rod
20 783-04285D Plate Support, Dash, RH
22 783-04323D Plate Support, Dash, LH
23 710-0751 Screw, 1/4-20, .620, Gr5
24 710-1652 Screw, 1/4-20x.625
25 712-04064 Nut, Flange Lock, 1/4-20, GrF, Nylon
26 731-04949 Lens, Grill
27 731-05522 Louvered Cover, Hood
28 736-0176 Wash, Flat, .265 x .938 x .120
29 731-05165 Plenum, Hood
30 751-0603 Cap, Fuel
31 751-0658E Fuel Tank, 3 Gal.
32 746-1086 Throttle Control, 39”
33 746-1085A Choke Control, 37.5”
34 725-1752 Switch, PTO
35 725-04036B Indicator Monitor w/ Reminder
36 725-04227A Ignition Switch Module
37 725-1745 Key, Plastic Cover
38 725-0963 Lamp, 12V
39 725-1649 Lamp Socket
— 629-04083 Headlamp Harness
— 629-04336 Wiring Harness, Tractor
Model
P805K
