MTD P805K - Page 39

39
REF.
NO.
PART
NUMBER DESCRIPTION
1 618-0376A Transmission Assembly, 2-Speed
2 618-04015 Pulley Assembly, Variable Speed
3 647-04023 Rod Assembly, Shift, 2-Speed
4 710-0176 Screw, 5/16-18, 2.75, Gr5
5 710-0347 Screw, 3/8-16, 1.75, Gr5
6 710-0642 Screw, 1/4-20, 0.750
7 710-0650 Screw, 5/16-18, 0.875
8 710-0726 Screw, 5/16-12, 0.750
9 710-0805 Screw, 5/16-18, 1.50, Gr5
10 710-0809 Screw, 1/4-20, 1.250
11 710-1007 Screw, Sems, 3/8-16, 1.500
12 710-3011 Screw, 3/8-16, 2.25, Gr5
18 712-0241 Nut, Hex, 3/8-24, Gr5
19 712-04063 Nut, Flange Lock, 5/16-18, GrF, Nylon
20 712-04065 Nut, Flange Lock, 3/8-16, GrF, Nylon
22 712-0431 Nut, Flange Lock, 3/8-16, GrF,
23 712-0702 Nut, Flange, 7/16-20, Gr2
24 714-0507 Pin, Cotter, 3/32 x .750
25 718-0771A Hub, Pulley, 1/2 Spline
26 720-04028 Knob, Shift
27 723-3018 Ball, Joint
28 732-0478 Extension, Spring 6.12
29 732-0716C Spring, Extension, .59 OD x 4.00
30 732-0963 Spring, Extension, .50 Dia x 6.37
31 736-0105 Washer, Bell, .375 x .870 x .063
32 736-0169 Washer, Lock, 3/8, Regular Duty
33 736-0642 Washer, Flat, .44x.75x.06, Ht Spcl
34 736-3010 Washer, Flat, .407x.812x.135, Ht
35 738-0322 Screw, Shoulder, .625 Dia x .217
36 738-0372B Spacer, Shoulder, 1.00 x .38 x .38
37 747-04136 Brake Rod
38 747-1127 Adjustment Rod, Idlr, 3/8
39 747-1185A Rod, Belt Guard
40 750-0566A Spacer, .260 x .372 x 1.030
41 754-0467 Belt, V-Type
42 647-0031B Control Assembly, Brake
REF.
NO.
PART
NUMBER DESCRIPTION
43 647-0032A Control Assembly, Speed
44 683-0266 Pedal Assembly, Control
45 710-1260A Screw, 5/16-18, 0.750
46 710-1611B Screw, 5/16-18, 0.750
47 711-04159B Pin, 3/8-16 x 2.68
48 712-3004A Nut, Flange Lock, 5/16-18, Gr5
49 714-0104 Pin, Cotter, .072 Dia. x 1.13
50 714-0111 Pin, Cotter, 3/32, 1.0
51 732-0335 Spring, Compression, .405 x 1.17
52 732-0955 Spring, Extension, .50 OD x 1.41
53 735-0662 Pad, Drive Control
54 735-3049 Pad, Brake
55 736-0119 Washer, Lock, 5/16, Regular Duty
56 736-0187 Washer, Flat, .64 x 1.24 x .06
57 736-0262 Washer, Flat, .385 x .870 x .092
58 736-3008 Washer, Flat, .344 x .750 x .120
59 738-0155 Shoulder Screw .437 Dia x .162
60 738-0380 Screw, Shoulder, .50 x .27 , 3/8-16
61 741-0225 Bearing, Hex Flange
62 741-3065B Bearing, Hex Flange, .628 ID, Split
63 747-04093 Control Rod, Brake Lock
64 747-04096 Control Rod, Cruise
65 747-04521 Pedal, Brake
66 748-04039B Latch, Cruise
67 783-04612 Bracket, Steering Support
68 783-0732A Bracket, Lockout
69 618-04200 Pulley Bracket
70 710-0627 Screw, 5/16-24, .75
71 710-3015 Screw, 1/4-20, .75
72 712-3027 Nut, Flange Lock, 1/4-20
73 718-04012 Bearing Cup
74 736-0362 Washer, Flat, .330 x 1.25 x .06
75 741-0600 Ball Bearing
76 710-0859 Screw, 3/8-16, 2.5
77 748-0415B Spacer, .385 x .635 x 1.54
Model
P805K
