MTD P805K - Page 44

44
6
1
2
4
REF.
NO.
PART
NUMBER DESCRIPTION
1 783-04419B Bracket, Clutch
2 710-0726 Screw, 5/16-12, .75
3 710-1260A Screw, 5/16-18, .75
4 710-04379A Screw, Hex Cap, 7/16-20 x 3.50 GR5
5 736-0171 Washer, Lock, 7/16
6 717-1774B Clutch, PTO
7 736-0277 Washer, Flat, 1.031 x 1.62 x .095
8 736-0277 Washer, Flat, 1.031 x 1.62 x .095
9 783-04467 Deck Stop
10 756-0639A Pulley, 3.56”
8
9
5
Model
P805K
10
