MTD V55D - Parts List Details

15
8
Parts List
IMPORTANT
For a proper working
machine, use Factory
Approved Parts. V-BELTS
are specially designed to
engage and disengage
safely.A substitute
(non OEM) V-Belt can
be dangerous by not
disengaging completely.
To order replacement
parts, call
1-800-800-7310
or visit us on
the web at
www.mtdproducts.com
Ref.
No.
Part No. Description
1 731-2626 Bail Cover
2 747-1161A Blade Control
3 746-0957 Control Cable 37.25-inch
4 726-0240 Cable Tie
5 664-04065 Grass Bag Assembly
6 747-04080A Grass Bag Frame
7 746-04206A Variable Speed Cable
8 731-05642 Trailshield
9 731-05865 Rear Door
10 687-02280A Height Adj. Bracket Assy - LH
687-02279A Height Adj. Bracket Assy - RH
11 787-01537 21-inch Deck
12 732-04317 Extension Spring
13 687-02193A Front Height Adj. Assy - LH
687-02194A Front Height Adj. Assy - RH
14 750-04405 Sleeve Spacer .52 ID x 1.8 Lg
15 715-0221 Dowel Pin
16 618-04377A Transmission
17 710-1650 Shoulder Screw
18 731-05013A Deck Cover
19 782-5002B Front Baffle
20 750-04818 Spacer, Sleeve
21 754-04082A V-Type Belt
22 787-01258A Cable Mount Bracket
23 748-04082 Blade Adapter
24 742-0741 21-inch Mulching Blade
25 736-0524B Blade Bell Support
26 710-1257 Screw 3/8-24 x 2.5
27 736-0277 Flat Washer, 1.031 x 1.620 x .095
28 756-04160 Key Half Pulley
29 756-04161 Upper Half Pulley
30 750-04404 Sleeve Spacer, .52 Lg x 9.10
31 687-02347 Front Bearing Assembly
32 787-01298 Adjustment Plate RH
787-01299 Adjustment Plate LH
33 687-02334 Pivot Plate Assembly
34 732-0706 Spring Lever RH
732-0707 Spring Lever LH
35 736-0474 Flat Washer 1.01 x 1.5 x .035
36 716-0102 Snap Ring
37 782-7551A Wheel Cover
38 717-1762 Spur Gear 14T RH
Ref.
No.
Part No. Description
717-1761 Spur Gear 14T LH
39 710-04531 Screw 1/4-20 x .39
40 734-2042 Front Wheel 8 x 2.125 Zag
41 731-0981A Hubcap
42 710-0216 Screw 3/8-16 x .75
43 720-0426 Knob
44 736-0447 Wave Washer 1.5 x 1 x .029
45 710-1008 Screw TT 3/8-16 x 1.875
46 712-04065 Flange Lock Nut 3/8-16
47 782-5004B Rear RH Baffle
48 710-1652 Screw TT 1/4-20 x .625
49 720-0312 Foam Grip
50 738-04266 Shoulder Screw
51 734-04093 Rear Wheel
52 732-0866 Spring Lever
53 687-02335 Pivot Arm Assembly RH
687-02336 Pivot Arm Assembly LH
54 753-05096A Speed Control Assembly
55 714-0104 Hairpin Clip
56 749-04206A Upper Handle
57 710-0703 Screw 1/4-20 x .75
58 631-0075B Engine Spacer
59 732-04090A Torsion Spring RH
60 710-1205 Eye Bolt
61 747-04588 Pivot Rod
62 782-5003A Rear Baffle LH
63 710-1017 Screw AB 1/4-14 x .625
64 712-0397 Wing Nut
65 749-0928A Lower Handle
66 710-1174 Carriage Bolt 5/16-18 x 2
67 720-04072 Star Knob
68 720-0279 Handle Knob
69 710-04329 Torx Screw
70 710-0896 Screw, 1/4-14 x .625
71 732-04294 Belt Keeper Wire
72 728-0173 Rivet, Pop
73 736-0182 Spring Washer, .500 x 1.00 x .022
74 736-0931 Washer, Flat, .203 x .403 x .040
75 787-01570 Bracket, Belt Keeper
76 787-01550 Bracket, Belt Keeper
77 732-04089A Torsion Spring LH
