MTD YARD MACHINES 607 - Page 35

35
REF.
NO.
PART
NO. DESCRIPTION
2 710-0604A Self-tapping Screw, 16-18 x .625
3 783-0726A RH Pivot Support Bracket
4 783-0727 LH Pivot Support Bracket
5 783-0728 Pivot Bar Bracket
6 710-0514 Hex Cap Screw, 3/8-16 x 1 (Grade 5)
7 711-1408 RH Drag Link
8 711-1409A LH Drag Link
9 712-0240 Jam Nut, 7/16-20 (Grade 2)
10 712-0241 Hex Nut, 3/8-24 (Grade 2)
11 712-0431 Flange Lock Nut, 3/8-16
12 712-0459 Flange Lock Nut, 7/16-20
13 712-3004A Flange Lock Nut, 5/16-18
14 717-1550D Steering Gear, 11/90 Ratio
15 717-1554 Steering Pinion Gear
16 723-0448A Ball Joint, 7/16-20
17 736-0169 Lock Washer, 3/8
18 736-3084 Flat Washer, .51 x 1.12 x .06
19 738-1001A Steering Shaft, .625 OD x 24.4
20 741-0475 Plastic Bushing, .38 ID
21 741-0656 Hex Flange Bearing, 5/8
22 738-0372A Shoulder Spacer, .38 ID
23 631-0027 Standard Steering Wheel, 13.25
24 731-0220 Steering Wheel Cap, Round
25 638-0019 LH Axle Assembly, .625 Diameter†
638-0021 LH Axle Assembly, .625/.750 Diameter‡
26 638-0020 RH Axle Assembly, .625 Diameter†
638-0022 RH Axle Assembly, .625/.750 Diameter‡
27 683-0128A Steel Pivot Bar
28 712-0431 Flange Lock Nut, 3/8-16
29 714-0470 Cotter Pin
30 726-0214 Push Cap, .625
31 736-0162 Flat Washer, .64 x 1.0 x .12
32 736-0187 Flat Washer, .64 x 1.24 x .06†
736-0316 Flat Washer, .78 x 1.589 x .06‡
33 736-0285 Flat Washer, .635 x 1.589 x .06
34 738-1011 Shoulder Screw, .5 x 2.2, 3/8-16
35 741-0659 Flange Bearing, .632 ID x .937 OD†
741-0660 Flange Bearing, .76 ID x .937 OD‡
36 634-0105A Wheel Assembly, 15 x 6 x 6
Square Shoulder
634-0056A Wheel Assembly,15 x 6 x 6
Round Shoulder
634-0172 Rim Assembly Only
734-0255 Air Valve (Not Shown)
734-1731 Tire Only, Square Shoulder
734-0864 Tire Only, Round Shoulder
37 734-2290 Deluxe Hub Cap (Ref. 33 Required)
38 783-0653D Steering Support Bracket
39 738-0143 Shoulder Screw, 3/8-16
40 736-0331 Bell Washer, .39 x 1.13 x .062
41 710-1260A Self-tapping Screw, 5/16-18 x .75
42 731-1869 Deluxe Steering Wheel
43 731-1904 Steering Wheel Cap, w/ Icon
44 731-0484A Standard Hub Cap
(Ref. 33 Not Necessary)
45 719-0399B Cast Iron Pivot Bar†
719-0525B Cast Iron Pivot Bar‡
46 736-0242 Bell Washer, .34 x .872
47 710-0643 Hex Bolt, 5/16-18 X 1
48 731-1291A Pivot Bar End Cap w/ Fitting
49 731-1649 Pivot Bar End Cap w/o Fitting
REF.
NO.
PART
NO. DESCRIPTION
†Models equipped with a 42-inch deck.
‡Models equipped with a 46-inch deck.
Models 607, 608
& 609
NOTE: Tractor features vary by model. NOT all parts listed above and pictured on the previous page are standard equipment.
