REPLACEMENT PARTS - MODEL Y765
2-CYCLE GAS TRIMMER
PPN 41DD765G900
Issued 6/09
Item Part No. Description
1 753-04927 Throttle Housing Assembly (includes 2 & 3)
2 791-610314 Throttle Trigger Spring
3 791-181807 Throttle Trigger
4 753-04901 Throttle Cable
5 791-153064 D-Handle Assembly (includes 6)
6 791-181587 D-Handle Hardware
7 753-06164 Drive Shaft Housing Assembly (includes 8)
8 753-05211 Flexible Drive Shaft
9 753-06125 Shield Mounting Hardware
10 753-06123 Shield Assembly (includes 11)
11 753-06126 Blade Assembly
12 753-05698 Anti-Rotation Screw
13 753-06165 Gearbox Assembly (includes 14-18)
14 753-04284 Outer Spool Assembly (includes 15)
15 791-610660 Retainer
16 791-610317B Spring
17 753-1155 Inner Reel
18 791-153066B Bump Head Knob Assembly
Optional Acessories
* 791-153577B Spool & 0.080 in. (2.03 mm) Line Assembly
1
4
3
2
1
5
6
7
8
10
15
9
14
11
16
17
18
6
12
13
