MTI RAPIDDOC PRO KIOSK - Mounting Plate Template

RAPIDDOC
®
PRO KIOSK INSTALLATION GUIDE
9
MTI P/N 063-00180 rev E ©2021 MTI All Rights Reservedwww.MTIGS.com | T:801.653.3807
Print this document at 100% (or ‘Actual Size’) to assist in placing the RapidDoc
®
Mounting Plate.
3.9376 in
3.9376 in
Drill Hole
FRONT
MOUNTING PLATE TEMPLATE
3” hole for Optional
Through-Hole
Mounting Accessory
-CONTROLLED DOCUMENT- 063-00180 E-0 Status: Approved ECO-112676
