MTS Sensors Temposonics ET Series Brief Instructions

Temposonics
®
E-Series
Brief Instructions
I 6 I
3.1 Temposonics
®
E-Series EH
Available outputs:
• Analog
• Start / Stop
• SSI
• CANopen
• IO-Link
Available outputs:
• Analog
• Start / Stop
• SSI
• CANopen
• IO-Link
Nameplate (e.g. E-Series EP CANopen)
3. Identification
(rod sensor)
EP00600MD341C304241Z02
FNr.: 1516071
Sensor model
Stroke length (e.g. 600 mm)
Connection type
Output
Baud rate
Resolution
Multi-position measurement
Part no.
Serial number
WeekYear
Sensor electronics housing
Position magnet
(Ring-, U- or block magnet)
Pressure-proof rod
with sensor element
Threaded flange
(M18×1.5-6g or ¾"-16 UNF-3A)
Connector / cable outlet
Sensor electronics
housing
Mounting clamp
Sensor profile with sensor element
Position magnet
(Magnet slider, U- or block magnet)
Ground lug
Connector outlet
3.2 Temposonics
®
E-Series EP (profile sensor)
NOTICE
Approvals and certificates
You will find approvals and certificates in
the sensor specific operation
manuals.
Manuals, Software & 3D Models
available at: www.mtssensors.com
