9. Appendix I
Safety Declaration
Dear Customer,
If you return one or several sensors for checking or repair, we need you to sign a safety declaration. The purpose of this declaration is to ensure
that the returned items do not contain residues of harmful substances and / or that people handling these items will not be in danger.
MTS Sensors order number: ________________________________
Serial number(s): _________________________________________
Sensor type(s): __________________________________________
Sensor length(s): ________________________________________
The sensor has been in contact with the following materials:
In the event of suspected penetration of substances into the sensor,
consult MTS Sensors to determine measures to be taken before
shipment.
Do not specify chemical formulas.
Please include safety data sheets of the substances, if applicable.
Short description of malfunction:
Corporate information
Company: _______________________________________________
Address: _______________________________________________
_______________________________________________________
Contact partner
Name: _______________________________________________
Phone: _______________________________________________
E-mail: _______________________________________________
We hereby certify that the measuring equipment has been cleaned and neutralized.
Equipment handling is safe. Personnel exposure to health risks during transport and repair is excluded.
DateSignatureStamp
Tel. + 49 - 23 51- 95 87 0
Fax. + 49 - 23 51- 5 64 91
info.de@mtssensors.com
www.mtssensors.com
GERMANY
MTS Sensor Technologie
GmbH & Co.KG
Auf dem Schüffel 9
58513 Lüdenscheid, Germany
USA
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513, USA
Tel. +1 919 677-0100
Fax +1 919 677-0200
info.us@mtssensors.com
www.mtssensors.com
Safety Declaration
Dear Customer,
If you return one or several sensors for checking or repair, we need you to sign a safety declaration. The purpose of this declaration is to ensure
that the returned items do not contain residues of harmful substances and / or that people handling these items will not be in danger.
MTS Sensors order number: ________________________________
Serial number(s): _________________________________________
Sensor type(s): __________________________________________
Sensor length(s): ________________________________________
The sensor has been in contact with the following materials:
In the event of suspected penetration of substances into the sensor,
consult MTS Sensors to determine measures to be taken before
shipment.
Do not specify chemical formulas.
Please include safety data sheets of the substances, if applicable.
Short description of malfunction:
Corporate information
Company: _______________________________________________
Address: _______________________________________________
_______________________________________________________
Contact partner
Name: _______________________________________________
Phone: _______________________________________________
E-mail: _______________________________________________
We hereby certify that the measuring equipment has been cleaned and neutralized.
Equipment handling is safe. Personnel exposure to health risks during transport and repair is excluded.
DateSignatureStamp
Tel. + 49 - 23 51- 95 87 0
Fax. + 49 - 23 51- 5 64 91
info.de@mtssensors.com
www.mtssensors.com
GERMANY
MTS Sensor Technologie
GmbH & Co.KG
Auf dem Schüffel 9
58513 Lüdenscheid, Germany
USA
MTS Systems Corporation
Sensors Division
3001 Sheldon Drive
Cary, N.C. 27513, USA
Tel. +1 919 677-0100
Fax +1 919 677-0200
info.us@mtssensors.com
www.mtssensors.com
CYLINDER PORT DET AILS
5
NOTES:
1. Dimensions and tolerances based on ANSI Y14.5-1982.
2. MTS has extracted all pertinent information from
MS33649 to generate this document.
3. PD must be square with surface B within 0.005 FIM
across 2.250 dia minimum.
4. PD must be concentric with 2.250 dia within 0.030 FIM
and with 0.769 dia within 0.005 FIM.
5. Surface texture ANSI B46.1-1978
6. Use O-ring MTS part number 560315 for correct sealing.
7. The thread design shall have sufficient threads to meet
strength requirements of material used.
8. Finish counter-bore shall be free from longitudinal and
spiral tool marks. Annular tool marks up to 32
microinches maximum will be permissible.
2.250 in. Minimum dia.
Specifies Surface B
120 0 30'
0.094 in.
+ 0.015
- 0.000
See Detail C
3/4-16 UNF-2B Thread
See Notes 3 And 4
32 in.
32 in.
125 in.
- B -
1.105 in.
Minimum
Full Thread
Depth
0.875 in. dia.
+ 0.015
- 0.000
0.769 in. dia.
+ 0.015
- 0.000
0.500 in.
dia.
0.005 in. dia., FIMA
45 5
15 1
0.094 in. max.
0.008 in.
0.004 in.
0.125 in.
0.125 in.
3/4-16 UNF-2B Thread
R
0.813 in. dia.
0.002 in.
0.106 in.
0.008 in.
A
0.008
A
0.004
A
R0.015 in.
max.
Pitch
dia.
1.180 in.
Recommended
Minimum
Spotface
Diameter
See Note 1
0.866 in. dia.
Minimum
See Note 2
1.100 in.
See Note 4
1.250 in.
See Note 3
See Note 4
0.500 in. dia. Ref.
See Note 4
SAE - 8 Port Size
0.094 in. Ref.
See Note 8
0.030 in. 0.010 R
0.020 in. R
Maximum
45 5
PORT DETAIL (PD) FOR RH5-S:
PORT DETAIL (PD) FOR RH5-T:
NOTES:
1. If face of port is on a machined surface, dimensions
1.180 and 0.094 need not apply as long as R0.008/0.004
is maintained to avoid damage to the O-ring during
installation.
2. Measure perpendicularity to A at this diameter.
3. This dimension applies when tap drill cannot pass
through entire boss.
4. This dimension does not conform to SAE J1926/1.
Detail C
