R-Series V Analog
Operation Manual
I 34 I
8. Technical data
8.1 Technical data Temposonics
®
RP5
Output
Analog Voltage: 0…10 /10…0/−10…+10/+10…−10 VDC (min. controller load > 5 kΩ)
Current: 4(0)…20/20…4(0) mA (min./max. load 0/500 Ω)
Measured output variables Position for one or two position magnets
Position + speed (without direction) or velocity (with direction) for one position magnet
Position for one position magnet + temperature inside the sensor electronics housing
Measurement parameters
Position measurement
Null/Span adjustment 100 % of electrical stroke
Resolution 16 bit (internal resolution 0.1 µm)
Linearity deviation
4
< ±0.01 % F.S. (minimum ±50 µm)
Repeatability < ±0.001 % F.S. (minimum ±1 µm)
Hysteresis < 4 µm
Update time
Stroke length ≤ 1200 mm ≤ 2400 mm ≤ 4800 mm ≤ 6350 mm
Update time 0.5 ms 1.0 ms 2.0 ms 5.0 ms
Velocity measurement
Range 0.01…10 m/s or 1…400 in./s
Deviation ≤ 0.05 %
Resolution 16 bit (minimum 0.01 mm/s)
Operating conditions
Operating temperature −40…+85 °C (−40…+185 °F)
Humidity 90 % relative humidity, no condensation
Temperature coef cient < 30 ppm/K
Ingress protection IP67 (connectors correctly  tted)/IP68 for cable outlet
Shock test 150 g/11 ms, IEC standard 60068-2-27
Vibration test
30 g/10…2000 Hz, IEC standard 60068-2-6 (excluding resonant frequencies)
EMC test Electromagnetic emission according to EN 61000-6-3
Electromagnetic immunity according to EN 61000-6-2
The sensor meets the requirements of the EC directives and is marked with
Magnet movement velocity Magnet slider: Max. 10 m/s; U-magnet: Any; block magnet: Any
Design / Material
Sensor electronics housing Aluminum (painted), zinc die cast
Sensor pro le Aluminum
Stroke length 25…6350 mm (1…250 in.)
Mechanical mounting
Mounting position Any
Mounting instruction
Please consult the technical drawings on page 11
Electrical connection
Connection type 1 × M16 male connectors (6 pin) or cable outlet
Operating voltage 12…30 VDC ±20 % (9.6…36 VDC)
Power consumption < 3.25 W
Dielectric strength 500 VDC (DC ground to machine ground)
Polarity protection Up to −36 VDC
Overvoltage protection Up to 36 VDC
4/ With position magnet # 251 416-2
