Questions and Answers:

L
Leonard AliAug 16, 2025
What to do if the MTU 16V 2000 G23 does not turn when starter is actuated?
- C
  Christopher WilsonAug 16, 2025
  If the MTU Engine doesn't turn when you actuate the starter, there are several potential causes. It could be due to a low or defective battery, in which case you should charge or replace it. Defective cable connections can also be the reason, so check if they are properly secured. Issues with the engine wiring or starter itself could be the problem, so check the cable connections. Also, make sure that the assemblies or connectors are seated correctly by performing a visual inspection, and check for loose plug-in connections. If the running gear is blocked, preventing manual barring of the engine, it is recommended to contact Service.
J
James ReynoldsAug 19, 2025
Why MTU 16V 2000 G23 Engine does not reach nominal speed?
- R
  richardmurphyAug 19, 2025
  The MTU Engine might not reach its nominal speed due to several reasons. A clogged fuel prefilter or fuel filter could be restricting fuel flow, so replace them. A clogged air filter could also be the cause, so check the signal ring position of the service indicator. Other potential causes include a defective injector or injection pump, so replace them. If the engine is overloaded, it is recommended to contact Service.
H
Harry BarryAug 22, 2025
What to do if MTU Engine turns but does not fire?
- R
  Rebecca PerkinsAug 22, 2025
  If the MTU Engine turns but doesn't fire, it could be due to a low or defective battery, so charge or replace it. Also, the fuel system might not be vented, so vent the fuel system. For other issues, it is recommended to contact Service.
P
Patricia AndersonAug 26, 2025
Why is my MTU 16V 2000 G23 exhaust gas black?
- T
  Thomas RogersAug 26, 2025
  Black exhaust gas from the MTU Engine can be caused by several factors. A clogged air filter could be restricting airflow, so check the signal ring position of the service indicator. A defective injector or injection pump could also be the culprit, so replace them. If the engine is overloaded, it is recommended to contact Service.
C
Christian McgrathAug 28, 2025
How to fix uneven firing of MTU Engine?
- D
  David PowellAug 28, 2025
  Uneven firing of the MTU Engine can stem from several causes. A defective injector or injection pump could be the reason, so replace them. Additionally, the fuel system might not be vented properly, so vent the fuel system. For other issues, it is recommended to contact Service.
N
Nicholas GrantAug 31, 2025
What causes MTU Engine speed to be unsteady?
- C
  Claudia SmithAug 31, 2025
  Unsteady engine speed in the MTU Engine can be attributed to a few potential issues. A defective injector or injection pump could be the cause, so replace them. Alternatively, the fuel system might not be properly vented, so vent the fuel system. For other issues, it is recommended to contact Service.
S
shirleyschwartzSep 3, 2025
What causes high charge-air temperature in MTU 16V 2000 G23 Engine?
- A
  aalvarezSep 3, 2025
  High charge-air temperature in the MTU Engine can result from a few issues. An incorrect coolant concentration could be the cause, so check it. Additionally, a high air-intake temperature could be the problem, so check the fans and air supply/ventilation ducts. If the engine is contaminated, it is recommended to contact Service.
G
Gary MartinSep 6, 2025
What causes blue exhaust gas from MTU Engine?
- T
  Tanya CooperSep 6, 2025
  Blue exhaust gas from the MTU Engine may indicate that there is too much oil in the engine, so drain engine oil. Another possible cause is a contaminated oil separator of the crankcase breather, so replace it. For other issues, it is recommended to contact Service.
A
April SchmittSep 9, 2025
What causes low charge air pressure in MTU 16V 2000 G23 Engine?
- A
  Anita SullivanSep 9, 2025
  Low charge air pressure in the MTU Engine can be caused by a clogged air filter, so check the signal ring position of the service indicator. If the engine is contaminated, it is recommended to contact Service.
S
Sean PatrickSep 12, 2025
Why is MTU 16V 2000 G23 Engine exhaust gas white?
- G
  gdavisSep 12, 2025
  White exhaust gas from the MTU Engine can occur for a few reasons. If the engine is not at operating temperature, run it until it reaches the correct temperature. Water in the fuel can also cause this issue, so check the fuel system on the fuel prefilter and drain the fuel prefilter. Leaking may be the cause, so it is recommended to contact Service.

MTU 16V 2000 G23 Specifications

General

Engine Type	Diesel
RPM	1500 RPM
Fuel Type	Diesel
Cooling System	Water-cooled
Aspiration	Turbocharged
Number of Cylinders	16
Configuration	V16
Application	Power generation
Cylinder Arrangement	V-type

Summary

Safety

General conditions

General safety rules, correct use, modifications, and spare parts policies for the engine.

Personnel and organizational requirements

Requirements for qualified personnel, organization, and protective equipment for engine operation.

Safety precautions when working on the engine

Detailed safety measures for engine operation, maintenance, and repair, covering various hazards.

Auxiliary materials, fire prevention and environmental protection

Safety guidelines for auxiliary materials, fire prevention, noise, environmental protection, and substance handling.

Product Summary

12/16/18V 2000 Standby operation: Application Group 3D, Air-cooled charge air, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)

Technical data for specific engine configurations under standby operation with optimized exhaust emission.

12/16/18V 2000 Continuous operation with variable load: Application group 3B, Air-cooled charge air, Optimized fuel consumption

Technical data for specific engine configurations under continuous operation with variable load and optimized fuel consumption.

12/16/18V Continuous operation with variable load: Application group 3B, Air-cooled charge air, Optimized exhaust emission (TA-Luft)

Technical data for specific engine configurations under continuous operation with variable load and optimized exhaust emission (TA-Luft).

12/16/18V Continuous operation with variable load: Application group 3B, Air-cooled charge air, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)

Technical data for specific engine configurations under continuous operation with variable load and optimized exhaust emission (EPA 40 CFR89 / Tier 1).

12/16/18V 2000 Continuous operation, unrestricted: Application group 3B, Air-cooled charge air, Optimized fuel consumption, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)

Technical data for unrestricted continuous operation with optimized fuel and exhaust emissions.

12/16/18V 2000 Standby operation: Application Group 3D, Water-cooled charge-air, Optimized fuel consumption

Technical data for standby operation with water-cooled charge-air and optimized fuel consumption.

12/16/18V 2000 Standby operation: Application Group 3D, Water-cooled charge-air, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)

12/16/18V 2000 Continuous operation with variable load: Application group 3B, Water-cooled charge-air, Optimized fuel consumption

12/16/18V Continuous operation with variable load: Application group 3B, Water-cooled charge-air, Optimized exhaust emission (TA-Luft)

12/16/18V Continuous operation with variable load: Application group 3B, Water-cooled charge-air, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)

12/16/18V 2000 Continuous operation, unrestricted: Application group 3B, Water-cooled charge-air, Optimized fuel consumption, Optimized exhaust emission (EPA 40 CFR89 / Tier 1)
