Operating Instructions
Diesel engine
12 V 2000 M86
12 V 2000 M96
12 V 2000 M96L
16 V 2000 M86
16 V 2000 M96
16 V 2000 M96L
MS150119/00E

Table of Contents

Questions and Answers

  • K
    kevinsmithAug 6, 2025
    What to do if MTU Engine doesn't turn over when starting?
    • J
      Jason HowardAug 7, 2025
      If your MTU Engine doesn't turn over when you try to start it, there are several potential causes. The battery might be flat or defective, in which case you should charge or replace it according to the manufacturer's documentation. Also, the cable connections on the battery might be defective, so check if they are properly secured according to the manufacturer's documentation. Other potential causes include defective engine wiring or a defective starter. Furthermore, the plug connections could be loose at the interface module EIM, so check those connections.
  • B
    brooksthomasAug 21, 2025
    Why does my MTU 16 V 2000 M86 Engine turn over but not start?
    • V
      Veronica FranklinAug 21, 2025
      If your MTU Engine turns over but doesn't fire, it could be due to several reasons. One possibility is poor rotation by the starter, which could be resolved by charging or replacing the battery as per the manufacturer's documentation. Another cause could be a flat or defective battery, which also requires charging or replacement following the manufacturer's instructions. Additionally, air in the fuel system may be the problem, requiring you to vent the fuel system. Other potential causes include faulty engine wiring or a defective engine governor ECU.

Summary

1 Safety

1.1 Important requirements for all products

General safety requirements applicable to all products, covering nameplate and intended use.

1.4 Safety requirements for startup and operation

Safety measures for initial startup and ongoing operation, including emergency stop.

1.5 Safety requirements for maintenance and repair work

Critical safety procedures before, during, and after maintenance or repair tasks.

2 General Information

2.1 Torque specifications for screws and nuts

Detailed torque values for various screw and nut sizes, according to MTN standards.

2.4 Engine layout

Visual identification and labeling of engine components on the free and driving ends.

3 Technical Data

3.1 12 V 2000 M86;M96;M96 L engine data

Performance and general specifications for 12-cylinder engine variants.

3.2 16 V 2000 M86;M86;M96 L engine data

Performance and general specifications for 16-cylinder engine variants.

3.4 Engine - Main dimensions

Key physical dimensions (length, width, height) for different engine models.

4 Operation

4.1 Putting the engine into operation after extended out-of-service periods (>3 months)

Step-by-step procedure for recommissioning an engine after long-term storage.

4.3 Operational checks

Routine inspections and checks to ensure the engine is operating correctly.

4.6 Emergency engine stop

Procedures for initiating an emergency engine shutdown and its implications.

5 Maintenance

5.1 Maintenance task reference table [QL1]

A comprehensive table listing maintenance tasks and their corresponding page references.

6 Troubleshooting

6.1 Troubleshooting

Guide to diagnosing and resolving common engine problems and their corrective actions.

7 Task Description

7.1 SOLAS

Instructions for installing SOLAS shielding as per MTN 5233 standard.

7.2 Engine

Describes manual barring and starting system cranking procedures for the engine.

7.5 Valve Drive

Details on cylinder head cover removal/installation and valve clearance adjustment.

7.9 Fuel Filter

Procedures for fuel filter replacement, draining, flushing, and element replacement.

7.16 Coolant Circuit, General, High-Temperature Circuit

Tasks related to engine coolant, including draining, filling, and checking levels.

7.23 Accessories for (Electronic) Engine Governor; Control System

Procedures for cleaning and checking connections of engine control system accessories.

8 Appendix A

8.1 List of abbreviations

An alphabetical list of abbreviations used throughout the manual with their explanations.

8.2 MTU contact persons;service partners

Information on how to contact MTU for support and service.

9 Appendix B

9.1 Special Tools

Lists special tools required for specific maintenance and repair tasks with part numbers.

MTU 16 V 2000 M86 Specifications

General IconGeneral
BrandMTU
Model16 V 2000 M86
CategoryEngine
LanguageEnglish
