Mueller GR-670 - Page 11

9
Burner
1
2
3
4
5
6
7
8
Oven
1 – 18”
2 – 30”
2 – 30”
Total
BTU/H
6,000
20,000
6,000
20,000
9,000
12,000
9,000
12,000
BTU/H
14,000
22,000
10,000
140,000
Position
FRONT LEFT (F/L)
FRONT MIDDLE LEFT (F/M/L) - DUAL
FRONT MIDDLE RIGHT (F/M/R)
FRONT RIGHT (F/R) - DUAL
BACK LEFT (B/L)
BACK MIDDLE LEFT (B/M/L)
BACK MIDDLE RIGHT (B/M/R)
BACK RIGHT (B/R)
Position
Left
Right
Broil Function, Right Oven only
8 Burners + 2 Ovens
NG Orifice
1.07
1.36*2+0.73
1.07
1.36*2+0.73
1.36
1.57
1.36
1.57
1.68
2.13
1.42
LP Orifice
0.74
0.89*2+0.53
0.74
0.89*2+0.53
0.9
1.0
0.9
1.0
1.09
1.4
0.94
Oven 1-18’’
Conventional
Oven 2-30’’
Conventional/Convection/Broil
1 2 3 4
5 6 7 8
