BURNER GRATES
● There are 4 Cast Iron Burner Grates. Secure the grates vertically, side-by-side on
top of the burners.
● Improper installation of the grates may result in scratching of the cooktop and/or
poor combustion.
● Always use the Burner Grates, and never place cookware directly on the Burners.
GRIDDLE
The Griddle can be placed on the range
cooktop in any one of the four Burner
Grate positions. Remove a Burner
Grate and position the Griddle so that
it covers 2 burners, Front and Back.
The griddle is reversible, such that
both sides, flat and ridged can be
heated. Ensure the grease trap is posi-
tioned toward the front of the range,
rather than toward the Top Vent.
OVEN RACKS
There are 2 Oven Racks for each oven. Slide the Stainless Steel Oven Racks into any
of the positions on the fixed Oven Rack Guides. The opening on the rack should be
positioned closest to the oven door, to assist with removal with the use of an oven
mitt/potholder.
Oven Rack
Guide
Oven Rack
Opening
Cool Air
Intake
DO NOT
OBSTRUCT
19
Reversible Griddle
Top Vent
Grease Trap
