Multicalor MC-EE Series - 3 Operating and Setting; General; The Control Panel; Basic Screen

Document: IV_MCEE_2016_11_22 Modifications reserved 5
3 Operating and setting
3.1 General
The MC-EE is fitted with an advanced controller based on an
Atmel RISC microcontroller and a high performance and high
eciency electronically controlled fan motor.
A control panel has been installed on the appliance to change
the dierent settings of the appliance. The control panel is
equipped with a capacitive touch screen and a TFT colour
screen.
3.2 The control panel
A control panel has been installed on the appliance to change
the dierent settings of the appliance. The control panel is
equipped with a capacitive touch screen and a TFT colour
screen.
3.2.1 Basic screen
The following information is displayed on the screen as
standard.
=
Multicalor
28-03-2015
3
53°
21:33
45%
1 2
3
4
56
7
Legend
Number Meaning
1 Function mode of the appliance
2
Air temperature
3 Time
4 Fan speed
5 Information menu button
6 Settings menu button
7 Date
3.2.2 Locking
If an error occurs that puts the safe operation of the appliance
at risk, the appliance will be locked. The cause for locking the
appliance is shown on the screen. The locking can be cancelled
by pressing the unlock button. If the error, however, has not
been resolved, the appliance will again be locked.
You must then contact your installer or the manufacturer for a
solution.
Fout
1
E40: NTC 1 ERROR
2
Legend
Number Meaning
1 Error message
2 Unload button
3.3 Changing settings
By pressing the setting button 3 the first screen of the setting
menu will be displayed.
1
Instellingen
1
2
3
4
Legend
Number Meaning
1 System settings
2 Settings in relation to the air heater operation
3 Screen cleaning
4 Back to the previous menu
7
6
System
Air heater
Screen cleaning
Error
Settings
