MULTIPLEX products have been constructed by model
aircraft pilots from their practical experience for practical
use.
Fly conscientiously! To fly closely above the heads of
other people is not a sign of ability. Real experts do not
need to show off in this way. Point this out to other pilots
for our common interest. . Always fly in such a way that
neither you nor others are endangered. Always
remember that even the best remote control can be
disturbed by external influences. Even many years of
flying without an accident are no guarantee for the next
minute of flying.
We, the MULTIPLEX team, wish you fun and success
with the construction and flying of your Easy Star.
MULTIPLEX Modellsport GmbH &Co. KG
Product care and development
Klaus Michler
Parts list BK # 21 4192
Serial pce Designation Material Dimensions
1 1 construction instructions A4
2 1 decoration sheet printed adhesive film 350 x 500 mm
3 1 left-hand side fuselage half foam Elapor complete part
4 1 right-hand side fuselage half foam Elapor complete part
5 1 canopy foam Elapor complete part
6 1 left-hand wing foam Elapor complete part
7 1 right-hand wing foam Elapor complete part
8 1 left-hand spar cover foam Elapor complete part
9 1 right-hand spar cover foam Elapor complete part
10 1 elevator foam Elapor complete part
11 1 rudder foam Elapor complete part
Small parts
20 3 Velcro knobs plastic 25 x 60 mm
21 3 Velcro loops plastic 25 x 60 mm
22 2 locking plate injection-molded plastic complete part
23 2 locking pin injection-molded plastic complete part
24 2 glue in rudder horn injection-molded plastic complete part
25 2 linkage connector metal complete part Ø 6mm
26 2 washer metal M2
27 2 nut metal M2
28 2 hexagon-socket worm screw
for connecting the linkage metal M3
29 1 Allan key metal size 1.5
Wire kit
30 2 steel wire for elevator and
rudder with Z-bend metal Ø 0.8 x 613 mm
31 2 external Bowden pull wire
sleeve for elevator and rudder plastic Ø 3/2 x 515 mm
32 1 external Bowden for the antenna plastic Ø 3/2 x 640 mm
33 2 internal Bowden pull wire sleeve plastic Ø 2/1 x 550 mm
for elevator and rudder
34 1 spar connector glass fibre reinforced tube Ø 8 x 1 x 495 mm
Driving set
40 1 propeller plastic 125 x 110 mm
41 1 drive motor Permax 400 6V complete part
