Multiplex FunCub User Manual

9
Examine your kit carefully!
MULTIPLEX model kits are subject to constant quality checks throughout the production process, and we sincerely hope that you
are completely satisfied with the contents of your kit. However, we would ask you to check all the parts before you start
construction, referring to the Parts List, as we cannot exchange components which you have already modified. If you find any
part is not acceptable for any reason, we will readily correct or exchange it once we have examined the faulty component. Just
send the offending part to our Model Department. Please be sure to include the enclosed complaint form, duly completed. We
are constantly working on improving our models, and for this reason we must reserve the right to change the kit contents in terms
of shape or dimensions of parts, technology, materials and fittings, without prior notification. Please understand that we cannot
entertain claims against us if the kit contents do not agree in every respect with the instructions and the illustrations.
# 21 4243
GB
Caution!
Radio-controlled models, and especially model aircraft, are by no means playthings in the usual sense of the term.
Building and operating them safely requires a certain level of technical competence and manual skill, together with
discipline and a responsible attitude at the flying field. Errors and carelessness in building and flying the model can
result in serious personal injury and damage to property. Since we, as manufacturers, have no control over the
construction, maintenance and operation of our products, we are obliged to take this opportunity to point out these
hazards and to emphasise your personal responsibility.
Recommended equipment:
Min. RX-7-light M-Link receiver Order No. 5 5810
or RX-9-DR M-LINK receiver Order No. 5 5812
or RX-7-Synth IPD 35 MHz A-band Order No. 5 5880
alternatively 40 / 41 MHz band Order No. 5 5882
2 Tiny-S servos (rudder, elevator) Order No. 6 5121
2 Nano-S servos (aileron) Order No. 6 5120
Optional: 2 / 3 additional Nano-S servos Order No. 6 5120
(for landing flaps and aero-tow release)
Power set:
“FunCub” power set Order No. 33 2649
including brushless motor, speed controller,
propeller, driver and accessories.
Recommended battery:
Li-BATT eco 3/1-2000 (M6) Order No. 15 7231
Adhesive:
Zacki ELAPOR® 20 g VE 20 Order No. 59 2727
Zacki ELAPOR® super liquid, 10 g VE 20 Order No. 59 2728
Tip!
“FunCub” power set, Li-BATT powered Order No. 33 3649
As above, but including Li-BATT eco 3/1-2000 (M6) flight battery
Tools:
Scissors, balsa knife, combination pliers, screwdriver.
Specification:
Wingspan 1400 mm
Overall length 980 mm
All-up weight approx. 1130 g
Wing area 38 dm²
Wing loading min. 30 g/dm²
RC functions Aileron, rudder, elevator, throttle
Optional landing flaps and aero-tow release

Multiplex FunCub Specifications

General

Wingspan	1400 mm
Recommended Battery	3S 2200mAh LiPo
Channels	4
Servos	4
Material	ELAPOR

Summary

Safety Notes and Precautions

General Safety Checks

Check model security, motor temperature, and propeller clearance before flight.

Flying Responsibly

Never fly towards or over people or animals.

Kit Contents and Specifications

Kit Examination and Recommended Equipment

Check all parts against the Parts List and identify recommended components.

Tools and Model Specifications

List of essential tools required and key technical specifications of the model.

Model Assembly - Fuselage and Tail

Important Assembly Notes

Use specific adhesives; work in well-ventilated areas for health and safety.

Fuselage and Control System Setup

Steps for assembling fuselage, servos, and control linkages.

Tailplane, Fin, and Tailwheel Assembly

Attaching the tailplane, fin, rudder horn, and tailwheel unit.

Main Undercarriage Installation

Preparing and attaching the main undercarriage unit to the fuselage.

Model Assembly - Wings and Power

Wing Assembly and Flap Preparation

Gluing wing spars and preparing ailerons and landing flaps.

Aileron and Flap Servo Installation

Installing servos for ailerons and landing flaps and connecting pushrods.

Power Set and Motor Bulkhead Setup

Installing the power set, motor bulkhead, and setting motor thrust angles.

Final Assembly and Pre-Flight Checks

Motor, Canopy, and Electronics Installation

Mounting the motor, canopy latches, flight pack, receiver, and aerial.

Control Surface Travel and Decal Application

Setting control surface throws and applying decorative decals to the model.

Center of Gravity and Pre-Flight Preparations

Balancing the model and performing essential pre-flight checks.

First Flight and Safety Guidelines

Launch Procedures and Flight Tips

Guidance on initial test flights, hand-launching, and general flying advice.

Responsible Flying and Maintenance

Emphasizes safe piloting, insurance, and regular model upkeep.

Parts List - FunCub

Main Aircraft Components

List of major aircraft components like fuselage, wings, tailplane, and undercarriage.

Small Parts, Motor Mount, and Rods

Details of small hardware, servos, linkages, motor mount, and wire/rod sets.

Undercarriage and Landing Gear Components

List of parts for the main and tail landing gear systems.

Spare Parts Identification

Wing and Tail Section Spares

Part numbers for wing panels and the complete tail set.

Fuselage Shells and Canopy Spares

Part numbers for fuselage shells, snakes, and the canopy.

Carbon Fiber Spars and Joiners

Part number for the carbon fiber spars and joiners.

Additional Spare Parts

Decal Sheet and Small Items Set

Part numbers for the decal sheet and the small items set.

Undercarriage and Wheel Spares

Part numbers for the main undercarriage, landing flap hinges, and wheels.
