Multiplex Funracer User Manual

8
Set contents
RR FunRacer
• ELAPOR
®
model, almost completely factory-built
• including ROXXY BL C35-42-1160kV outrunner
• Multiplex ROXXY BL-Control 755 S-BEC speed controller
• 10 x 7“ propeller
• 4 x MS-12016 MG Digi servos
• decals applied
RR FunRacer White Edition
• ELAPOR
®
model, 98% factory-built
• including ROXXY BL C35-42-1160kV outrunner
• Multiplex ROXXY BL-Control 755 S-BEC speed controller
• 10 x 7“ propeller
• 4 x MS-12016 MG Digi servos
• decal sheet
Accessories and tools
Required accessories
• 1x Zacki Elapor
®
20g # 85 2727 or
• 1x Zacki Elapor
®
super liquid 10g # 85 2728
• 1x ROXXY EVO Lipo 3-2600M 40C # 316656
• 1x receiver RX-6-DR light M-LINK 2.4 GHz # 5 5809
The following tools are required to assemble the model:
• Activator spray for CA adhesive
• Small cross-tip screwdriver
• Hex wrench 1.5
• 10mm open-ended wrench
Optional accessories
EC-ELAPOR-COLOR
Red # 60 2800
Blue # 60 2801
Yellow # 60 2802
Orange # 60 2803
Green # 60 2804
Black # 60 2805
Gray # 60 2806
Luminous red # 60 2807
Blue metallic # 60 2808
Silver # 60 2809
List of components FunRacer
Serial
no.
Qty. Name Material Dimensions
1 1 Assembly instructions Paper DIN A4
2 1 Complaints form for models Paper DIN A4
3 1 ROXXY BL-Control 755 S-BEC instructions Paper DIN A4
4 4 Decal sheet "84" Printed adhesive lm Finished components
5 1 Fuselage fully assembled Elapor Finished component
6 1 Wing fully assembled Elapor Finished component
7 1 Elevator fully assembled Elapor Finished component
8 1 Canopy fully assembled Elapor Finished component
9 1 Rudder lling piece Elapor Finished component
10 1 Elevator linkage rod Metal 1.5x75mm
11 2 Wing screws Plastic M5x45
12 3 Mushroom head hook and loop tape Plastic 25x60mm
13 3 Velour hook and loop tape Plastic 25x60mm
EN

Multiplex Funracer Specifications

General

Motor type	Brushless
Engine type	Electric engine
Product type	Airplane
Construction type	Ready-to-Run (RTR)
Total surface area	190 cm²
Battery type	3S LiPo
Batteries required	Yes
Assembly time	15 min
Product color	Orange

Weight and Dimensions

Weight	920 g
Wingspan	920 mm
