14
Parts list KIT FunRay # 21 4334
Seq. no. Qty. Name Material Dimensions
82 1 Washer Metal Ø 8.4 mm
83 1 Lock washer Metal Ø 8.4 mm
84 1 Nut Metal M8
85 2 Cylinder head screw Metal M3 x 20 mm
86 2 Stop nut Metal M3
87 1 Oval countersunk head screw Metal M2.5 x 12 mm
89 1 Collet chuck (complete) Metal Ød 5 mm
90 1 Propeller driver Injected plastic Finished component
91 1 Spinner Injected plastic Finished component
Spinner/driver set
For further information about the contents of the replacement parts, please visit www. multiplex-rc.de
Replacement parts KIT FunRay # 21 4334
Art. no Description
1-00121 Fuselage, assembled (excl. RC + decals)
1-00122 Rudder, completed (excl. decals)
1-00123 Canopy and latch
1-00124 Wing set, completed (excl. RC + decals)
1-00125 Tailplane, completed (excl. decals)
733183 Spinner, propeller driver, taper collet, complete
1-00106 2 folding propeller blades, 11 x 7"
1-00126 Decal sheet
1-00127 "FunRay" control surface horn, 12 x 20 with
connector, 2 sets
1-00128 O-ring, 8 mm Ø (pack of 4)
1-00129 O-ring, 6 mm Ø (pack of 2)
1-00130 Retaining pin
1-00131 Small parts set
1-00132 Plastic parts set, wings
1-00133 Plastic parts set, fuselage + tail
Art. no. Description
1-00134 Tubes and GRP rod
1-00135 Leading edge set
1-00136 Square CFRP tube, 10 x 10 x 1010 mm
1-00407 Servo fairing, 1 pair
725136 Canopy lock (pack of 2)
1-00137 UNI connector retainer (pack of 5)
112065 HS-65HB servo
315076 ROXXY C35-48-990kv motor
318975 ROXXY BL-Control 755 S-BEC speed controller
1-00371 Clear plastic lm landing skids (front and rear)
1-00112 FunRay cable set (complete)
85032 Extension lead, 60 cm (for fuselage servos)
224350 Glider fuselage nose (for glider version)
723470 Tow-release (for glider version)
