Seq. no. Qty. Name Material Dimensions
40 1 Inner left leading edge Injected plastic Finished component
41 1 Inner right leading edge Injected plastic Finished component
42 1 Outer left leading edge Injected plastic Finished component
43 1 Outer right leading edge Injected plastic Finished component
44 1 Left leading edge lling piece Injected plastic Finished component
45 1 Right leading edge lling piece Injected plastic Finished component
46 2 Elevator unit leading edge Injected plastic Finished component
Leading edge set
Seq. no. Qty. Name Material Dimensions
50 1 Motor bulkhead with ange Injected plastic Finished component
51 1 Left wing root Injected plastic Finished component
52 1 Right wing root Injected plastic Finished component
53 4 Retaining clip Injected plastic Finished component
54 1 Retaining pin Injected plastic Finished component
55 1 M6 fuselage plug bracket Injected plastic Finished component
56 1 Servo holder fuselage Injected plastic Finished component
57 1 Elevator unit left wing root with catch Injected plastic Finished component
58 1 Elevator unit right wing root Injected plastic Finished component
59 1 Left elevator connector Injected plastic Finished component
60 1 Right elevator connector with horn Injected plastic Finished component
61 3 Recessed hinge pin Injected plastic Finished component
62 3 Recessed hinge pin support Injected plastic Finished component
63 1 Canopy nger-grip Injected plastic Finished component
64 2 Left servo hood Injected plastic Finished component
65 2 Right servo hood Injected plastic Finished component
Plastic parts set
Seq. no. Qty. Name Material Dimensions
68 1 Fuselage reinforcement tube CFRP square 10 x 8.4 x 1010 mm
69 2 Strut tube => tted in the wing ALU-CFRP square 10 x 8 x 822 mm
70 4 Aileron and camber-changing aps reinforcement tube Stainless steel tube Ø3 x Ø2.6 x 330 mm
71 1 Rudder reinforcement tube Stainless steel tube Ø3 x Ø2.6 x 200 mm
72 1 Left elevator unit reinforcement tube Stainless steel tube Ø3 x Ø2.6 x 200 mm
73 1 Right elevator unit reinforcement tube Stainless steel tube Ø3 x Ø2.6 x 120 mm
74 2 Elevator unit strut tube CFRP square 5.5 x 3.5 x 200 mm
75 2 GRP rod GRP Ø2 x 700 mm
Reinforcements (pipes and rods)
Parts list KIT FunRay # 21 4334
