31
WIRING SCHEMATICS
ELECTRONICALLY ACTIVATED STILL WATER BOOST
Page 1 of 1
02.10.2013
Section 6
STILL
VALVE
STILL
VALVE
SODA
VALVE
SODA
VALVE
CO2
WARNING
LAMP
24 VAC
TO STILL
VALVES
24 VAC
TO SODA
VALVES
SIGNAL
LAMP CO2
EMPTY
CONNECTION 5
TRANSFORMER
MAIN PCB BOARD
CONNECTION 32

TRANSFORMER
200 VA
CO2
PRESSURE
SWITCH
230 VAC
24 VAC
OUT
