Multiplex ICECORETM 15 User Manual

45
SECTION 8
EXPLODED VIEWS
GENERAL LAYOUT

Dimensions Icecore 15 Icecore 15
A  
B  933mm
C




D 524mm 
E  554mm
FIXED PLASTIC
LIFTING HANDLES

FUNNEL AND
FILLER CAP

ROTATING
LIFTING HANDLES

CONNECTION






CONNECTION
OVERFLOW
WATER OUTLET
DRAIN
