27
Part No. Description MaterialDimensions
No. off
1 1 KIT building instructions Paper, 80 g/m² A4
2 1 Decal set Printed adhesive film 500 x 175 mm
3 1 L.H. fuselage shell Moulded Elapor foam Ready made
4 1 R.H. fuselage shell, incl. fin Moulded Elapor foam Ready made
5 1 L.H. wing panel Moulded Elapor foam Ready made
6 1 R.H. wing panel Moulded Elapor foam Ready made
7 1 L.H. tailplane panel Moulded Elapor foam Ready made
8 1 R.H. tailplane panel Moulded Elapor foam Ready made
Small items set
20 3 Velcro tape, “mushroom” Plastic 25 x 60 mm
21 3 Velcro tape, “felt” Plastic 25 x 60 mm
22 3 Twin control surface horn Plastic Ready made
23 3 Twin pushrod connector Metal Ready made, 6 mm Ø
24 4 Socket-head grubscrew Metal M3 x 3 mm
25 1 Swivel pushrod connector Metal Ready made, 6 mm Ø
26 1 Washer Metal M2
27 1 Nut Metal M2
28 1 Allen key Metal 1.5 mm A/F
29 2 Pre-formed aileron pushrod (Z-bend) Metal 1 Ø x 50 mm
30 2 Countersunk screw (tailplane housing) Metal M2 x 8 mm
36 2 Wing servo well cover Plastic 35 x 35 mm
37 2 Cheesehead screw, glider nose-cone Metal M2.5 x 8mm
Plastic parts set
40 1 Fuselage hatch frame Inj. moulded plastic Ready made
41 1 Fuselage hatch Inj. moulded plastic Ready made
42 1 Fuselage fairing / motor bulkhead Inj. moulded plastic Ready made
43 1 Glider nose-cone Inj. moulded plastic Ready made
44 2 “Nano” servo frame, upright Inj. moulded plastic Ready made
45 1 L.H. servo fairing Inj. moulded plastic Ready made
46 1 R.H. servo fairing Inj. moulded plastic Ready made
47 1 L.H. wing retainer Inj. moulded plastic Ready made
48 1 R.H. wing retainer Inj. moulded plastic Ready made
49 1 Wing retainer plate Inj. moulded plastic Ready made
50 1 Tailplane bearing housing Inj. moulded plastic Ready made
51 1 Tailplane bearing housing cover Inj. moulded plastic Ready made
52 1 Tailplane joiner with shaft Inj. moulded plastic Ready made
53 1 Tailplane joiner with retainer Inj. moulded plastic Ready made
54 1 Tailplane crank Inj. moulded plastic Ready made
Wire and rod, wing spars
60 2 Wing spar CFRP flat strip 6 x 1.5 x 225 mm
61 1 Steel elevator pushrod, with Z-bend Metal 0.8 Ø x 210mm
62 1 Steel rudder pushrod, with Z-bend Metal 0.8 Ø x 275mm
63 1 Elevator snake inner sleeve Plastic 2 / 1 Ø x 170mm (230mm*)
64 1 Rudder snake inner sleeve Plastic 2 / 1 Ø x 230mm
65 1 Elevator snake outer sleeve Plastic 3 / 2 Ø x 140mm (200mm*)
66 1 Rudder snake outer sleeve Plastic 3 / 2 Ø x 180mm (200mm*)
67 1 Aerial sleeve Plastic 3 / 2 Ø x 320mm
68 1 L.H. fuselage longeron GRP rod 1.3 Ø x 470mm (510mm*)
69 1 R.H. fuselage longeron GRP rod 1.3 Ø x 510mm
70 1 Top fuselage longeron GRP rod 1.3 Ø x 276mm (510mm*)
* Supplied length => cut to length as required.
