PAGE 18 — B-SERIES TROWEL — PARTS & OPERATION MANUAL — REV. #1 (12/03/01)
TECHNICAL SPECIFICATIONS
MODEL J B
A 36.7 in. 931.6mm 34.5 in. 876.2mm
B 41.4 in. 1044.2mm 41.1 in. 1044.2mm
C 36.5 in. 927.1mm 46 1168.4mm
D 70.5 in. 1789.4mm 75.2 in. 1910.1mm
Weight 150 lb. 330 Kg 240 lb. 528 Kg
Sound Pressure* 94 dB 94 dB 97 dB 97 dB
Vibration** 2.0g 19.6m/s2 2.5g 24.5 m/s2
Blade Speed (max.) 129 rpm @ 4000 129 rpm @ 4000 129 rpm
@ 4000 129 pm @ 4000
engine rpm engine rpm engine rpm engine rpm
Blade Tip Speed (max.) 1182pm 6.0 m/s 1478 fpm 7.5m/s
*Sound pressure is A weighted. Measured at the operator’s ear
position while running the machine on curing concrete in a
manner most often experienced in “normal” circumstances.
Sound pressure may vary depending upon the condition of the
concrete. Hearing protection is always recommended.
B-SERIES TROWEL — TECHNICAL SPECIFICATIONS
**Vibration level indicated is the maximum RMS value obtained
at the handle grip while operating the machine on curing
concrete in a manner most often experienced in “normal”
circumstances. Values were obtained from all three axes of
motion. The values shown here represent the maximum RMS
value from these measurements.
